HISTORY INFORMATION FOR THE FOLLOWING MANUAL:
SERVICE MANUAL
MODEL NAME
KDP-57XBR2
KDP-57XBR2
KDP-65XBR2
KDP-65XBR2
ORIGINAL MANUAL ISSUE DATE: 7/2001
ALL REVISIONS AND UPDATES TO THE ORIGINAL MANUAL ARE APPENDED TO THE END OF THE PDF FILE.
REVISION DATE
7/2001
11/2001
1/2002
7/2002
9-965-432-04
REMOTE COMMANDER
RM-Y185
RM-Y185
RM-Y185
RM-Y185
REVISION TYPE
SUBJECT
No revisions or updates are applicable at this time.
Supplement - 1
Adjustment Manual Added
Correction - 1
Exploded View - Screen Frame Block P/N Corrected
Supplement - 2
B Board, Q-Box Assembly P/N Correction; IC001 P/N Correction
DIGITAL HIGH DEFINITION PROJECTION TV
RA-5A
DESTINATION
CHASSIS NO.
US
SCC-P69B-A
Canadian
SCC-P69B-A
US
SCC-P69A-A
Canadian
SCC-P69A-A
CHASSIS
