Setting Up the Projection TV
Connecting a DVD Player with Component
Video Connectors
DVD player
26
This is the preferred hookup to use if your DVD player has
component video out jacks.
1
Using three separate component video cables, connect the DVD
player's Y, P
and P
B
projection TV. Use the HD/DVD IN 5 or 6 connections.
The Y, P
and P
B
R
C
, or Y, B-Y and R-Y. If so, connect the cables to like colors.
R
2
Using an audio cable, connect the DVD player's Audio OUT
jacks to the projection TV's Audio IN jacks. Be sure to use the
same column of inputs that you used for the video connection
(HD/DVD IN 5 or 6).
Component video cables
Audio cable
You cannot record the signal from any equipment connected into the Y, P
jacks.
jacks to the Y, P
R
B
jacks on your DVD player are sometimes labeled Y, C
TV
AUDIO-R (red)
AUDIO-L (white)
and P
jacks on the
R
and
B
, P
B
R
