ZEUS4-VD INSTALLATION MANUAL
4

START UP

Insert SIM card to be used for ZEUS4-VD in your personal mobile phone.
ERASE THE PIN CODE!
Enter telephone numbers and the required operating parameters in SIM memory – at least 1
telephone No. (TN1) and 1 link (LN1) should be programmed (see installation manual).
Insert SIM card in the GSM module applied for the ZEUS4-VD device. The unit must be
power OFF when you insert the SIM!
Connect alarm inputs and outputs to ZEUS4-VD.
Connect the antenna to antenna connector.
Connect device to source power supply voltage.
Wait until LED3 display is turned ON (green) and LED1 (blue) starts flashing. This is set in
around 1 minute.
Connect the headset to Play/REC connector and record alarm messages.
ZEUS4-VD unit is now ready to operate.
NOTE: When the back-up battery 12V/1,2Ah is connected to the unit the main power supply
must be from 13,8V to 14,5V DC!
