ZEUS4-VD INSTALLATION MANUAL
Example: When you need to send an alarm beep message and SMS message to the first telephone
number, only alarm beep message to the second one and only SMS message to the third one. (See
the table below.)
Name
TN1
TN2V
TN3M
9.1.1 TN remote programming by SMS
For the upper example send the following SMS from the host phone to the ZEUS4-VD:
;TN1=042376678;TN2V=040719479;TN3M=040308350;
If you would like to receive confirmation SMS write "+" before SMS command:
;+TN1=042376678;TN2V=040719479;TN3M=040308350;
9.2

PROGRAMMING INPUT STATUS - IN

Alarm and reset input can be triggered in 4 different ways. The status of the input can either be
normal closed (N.C) or normal open (N.O.) with positive (+ 12V) or negative (GND) voltage.
When you need the input feedback information it is possible to receive SMS back when input will
return from alarm to normal position. (See cap.5.8 – SMS Messages organizer). To get return SMS
use IN=4,5 or 6.
IN = 0 – Normal Open – triggered with negative voltage (GND)
IN = 1 – Normal Close – breaking negative or positive voltage loop
IN = 2 – Normal Open – triggered with positive voltage (+ 12VDC)
IN = 3 – Input disable
IN = 4 = IN = 0 + input reset SMS
IN = 5 = IN = 1 + input reset SMS
IN = 6 = IN = 2 + input reset SMS
ZEUS4-VD PROGRAMMING TABLE
SIM CARD PHONE BOOK
Number
042376678 1st telephone number (alarm voice & SMS message)
040719479 2nd telephone number (alarm voice only)
040308350 3rd telephone number (SMS message only)
Description
10
