ZEUS4-VD INSTALLATION MANUAL
9.1

INPUTS AND TELEPHONE NO. LINKING - LN

It is possible to link each number or any combination of numbers to any of the four corresponding
inputs.
Programming table for linking the inputs and telephone numbers – LN
9.1.1
Default values:
Name Number (Default)
LN1
LN2
LN3
LN4
LN5
LN6
LN7
LN8
LN9
Example:
Name
LN8
LN1
LN2
LN3
LN4
LN7
9.1.2 LN remote programming by SMS
For the upper example send the following SMS from the host phone to the ZEUS4-VD:
;LN8=12;LN1=13;LN2=123;LN3=5;LN4=45;LN7=12;
If you would like to receive confirmation SMS write "+" before SMS command:
;+LN8=12;LN1=13;LN2=123;LN3=5;LN4=45;LN7=12;
ZEUS4-VD PROGRAMMING TABLE
SIM CARD PHONE BOOK
Input & telephone No. linking for 1
Input & telephone No. linking for 2
Input & telephone No. linking for 3
Input & telephone No. linking for 4
Power down and telephone No. linking (TN1 – TN0)
Low Battery and telephone No. Linking (TN1 – TN0)
Periodic test SMS and telephone No. linking (TN1 – TN0)
SIM card refill and telephone No. linking (TN1 – TN0)
Tamper switch and telephone No. linking (TN1 – TN0)
ZEUS4-VD PROGRAMMING TABLE
SIM CARD PHONE BOOK
Number
Refill SIM – SMS is sent to TN1 & TN2
12
13 Input1 is called/sent SMS to TN1 & TN3
123 Input2 is called/sent SMS to TN1, TN2 & TN3
5 Input3 is called/sent SMS to TN5
45 Input4 is called/sent SMS to send to TN4 & TN5
Periodic Test SMS is sent to TN1 & TN2
12
Description
st
alarm input (TN1 – TN0)
nd alarm input (TN1 – TN0)
rd alarm input (TN1 – TN0)
th alarm input (TN1 – TN0)
Description
12
