ZEUS4-VD INSTALLATION MANUAL
CLIP FUNCTION PARAMETER – TC
9.9
Ten telephone numbers which are stored into the phone book from TN1 to TN0 can manage
following functions using CLIP (Calling Line Identification Presentation) without making any cost
to the user GSM bill.
Trigger one of the ZEUS4-VD Output (parameter 1-4)
Switch the system ON/OFF (parameter 5)
System control with "Call-back" function (parameter 6)
NOTE: With one telephone number you can control only one function (for example trigger
only first output)!
To activate the CLIP function you must cancel call after 1-3 rings!
Programming table to define the CLIP functions – TC
9.9.1
Name
TC1
TC2
TC3
TC4
TC5
TC6
TC7
TC8
TC9
TC0
X=1-4 OUTPUT1 to OUTPUT4 controlling
X=5 System ON/OFF
X=6 Call back function
TC1 triggers OUTPUT3, TC2 switches the system ON/OFF and TC3 makes a call back to the
user's phone.
Example:
Name
TC1
TC2
TC3
ZEUS4-VD PROGRAMMING TABLE
SIM CARD PHONE BOOK
Number
First CLIP telephone number = TN1
x
x Second CLIP telephone number = TN2
x Third CLIP telephone number = TN3
Forth CLIP telephone number = TN4
x
x Fifth CLIP telephone number = TN5
x Sixth CLIP telephone number = TN6
Seventh CLIP telephone number = TN7
x
x Eight telephone number = TN8
Ninth CLIP telephone number = TN9
x
x Tenth CLIP telephone number = TN0
ZEUS4-VD PROGRAMMING TABLE
SIM CARD PHONE BOOK
Number
st
3 1 CLIP activates the Output 3
nd
5 2 CLIP switches system OFF/ON
rd
6 3 CLIP calls back from device to user
Description
Description
19
