TYPICAL INPUT CONNECTIONS
INPUT 1-4
N.O.
contact
GND
PROGRAMMING TABLE FOR INPUT STATUS
Default values:
Name
ION
IN1
IN2
IN3
IN4
Example:
Name
ION
IN1
IN2
IN3
IN4
9.2.1 IN parameter remote programming by SMS
For the upper example send the following SMS from the host phone to the ZEUS4-VD:
;ION=0;IN1=0;IN2=1;IN3=2;IN4=4;
If you would like to receive confirmation SMS write "+" before SMS command:
;+ION=0;IN1=0;IN2=1;IN3=2;IN4=4;
INPUT 1-4
N.O.
contact
+12V DC
ZEUS4-VD PROGRAMMING TABLE
SIM CARD PHONE BOOK
Number (Default)
0 Input status for system ON/OFF
0 Input status for alarm input 1
Input status for alarm input 2
0
Input status for alarm input 3
0
Input status for alarm input 4
0
ZEUS4-VD PROGRAMMING TABLE
SIM CARD PHONE BOOK
Number
OFF – connecting GND on ON/OFF input
0
Alarm activated by connecting to GND
0
Alarm activated by disconnecting GND or +12V
1
Alarm activated by connecting +12V
2
4 Alarm activated by connecting to GND + RST SMS
INPUT 1-4
N.C.
contact
GND
Description
Description
11
INPUT 1-4
N.O.
contact
+12V DC
