ZEUS4-VD INSTALLATION MANUAL
DIRECT ALARM OUTPUT – OD
9.8
If you would like to activate a local alarm (siren) you can program any ZEUS4-VD output for this
function. OD5 to OD8 are links between fictive inputs like telephone line failure, GSM failure to
dedicated output.
Type of the Output (ON/OFF or pulse time) is determined with parameter OS.
At the same time you can also control the outputs remotely by SMS or DTMF commands.
Possible programming parameters:
Name
OD1
OD2
OD3
OD4
OD5
OD6
OD7
OD8
Programming table for OD – direct alarm output
9.8.1
It is possible to choose different combinations between outputs and inputs
Example:
Name
OD1
OD2
OD3
OD4
OD5
OD6
OD7
OD8
9.8.2 OD remote programming by SMS
For the upper example send the following SMS from the host phone to the ZEUS4-VD:
;OD1=1;OD6=2;OD7=4;OD8=3;
If you would like to receive confirmation SMS write "+" before SMS command:
;+OD1=1;OD6=2;OD7=4;OD8=3;
ZEUS4-VD PROGRAMMING TABLE
SIM CARD PHONE BOOK
Output
No direct connection between input and output
No direct connection between input and output
No direct connection between input and output
No direct connection between input and output
Telephone line failure (only MC&VMC versions)
GSM network failure
System tamper
System ON/OFF (any of outputs)
ZEUS4-VD PROGRAMMING TABLE
SIM CARD PHONE BOOK
Output
1 Alarm on IN1 trigger output 1
No direct connection between input and output
0
0 No direct connection between input and output
0 No direct connection between input and output
X Telephone line failure (only MC&VMC versions)
GSM network failure on output 2
2
4 System tamper on output 4
3 System ON/OFF on output 3
18
Description
Description
