Swc 82(H)(K)3 - Swc 102(H)(K)3 - Alpha-InnoTec SWC Series Operating Manual

Technical data / Scope of supply
Performance data: Heating output / COP
at B0/W35 operating point to EN14511
at B0/W45 operating point to EN14511
Heating capacity ı COP
at B0/W55 operating point to EN14511
at B7/W35 flows analogous to B0/W35
Cooling capacity at max. flow rate (B15/W25), units with passive cooling: Identifier K
Limits of use
Heating circuit return min. I Heating circuit flow max.
Heat source return
additional operating points
Sound
Sound pressure level at 1m distance from edge of unit
Sound power level to EN12102
Heat source
Flow rate: minimum I nominal analogous to B0/W35 I maximum
Max. free heat pump pressure ∆p (with cooling ∆pK) ***) ı Flow rate
Approved anti-freeze
Anti-freeze concentration: Minimum frost protection down to
max. allowable operating pressure
Heating circuit
Flow rate: minimum I nominal analogous to B0/W35 I maximum
Max. free heat pump pressure ∆p (with cooling ∆pK) ı Volume flow
Pressure losses, heat pump ∆p ı Volume flow
max. allowable operating pressure
General unit data
Total weight (with cooling)
Box weight (with cooling) ı Tower weight (with cooling)
Refrigerant type ı Refrigerant capacity
Domestic hot water tank
Net volume
Impressed current anode
Domestic hot water temperature, heating pump mode I Electric heating element
Mixed water quantity according to ErP: 2009/125/EC (at 40°C, draw-off of 10 l/min)
Standing loss according to ErP: 2009/125/EC (at 65°C)
Maximum pressure
Electrics
Voltage code ı all-pole heat pump fusing *)**)
Voltage code ı Control voltage fusing **)
Voltage code ı Electric heating element fusing **)
Voltage code ı all-pole fusing for connection via a joint supply cable*)**)
WP*): effect. Power input at B0/W35 to EN14511 I Current input I cosφ
WP*): Max. machine current I Max. power input within the limits of use
Starting current: direct ı with soft starter
Degree of protection
Electric heating element output
Circulation pump power consumption, heating circuit I heat source
Other unit information
Safety valve, heating circuit I Heat source
Expansion valve, heating circuit I Heat source
Overflow valve I Changeover valve, heating -Domestic hot water
Vibration isolators, heating circuit I Heat source
*) Only compressor, **) Follow local regulations, ***) Figures for 25% mono-ethylene glycol
Subject to change without notice | 83056700fUK – Translation of the original operating manual | ait-deutschland GmbH
Monoethylene glycol I Propylene glycol I Methanol I Ethanol
included in scope of supply: • yes — no
included in scope of supply: • yes — no
SWC 82(H)(K)3 – SWC 102(H)(K)3
SWC 82(H)(K)3
kW ı COP 7,70 ı 4,90
kW ı COP 6,84 ı 3,61
kW ı COP 6,49 ı 2,91
kW ı COP 9,20 ı 5,96
kW
°C
min. I max. °C
...
dB(A)
dB(A)
l/h 1200 ı 1750 ı 2600
bar (bar) ı l/h 0,76 (0,70) ı 1750
• I • I • I •
°C
bar
l/h 650 ı 1300 ı 1600
bar (bar) ı l/h 0,57 (0,54) ı 1300
bar ı l/h — (—) ı —
bar
kg (kg) 175 (183)
kg (kg) ı kg (kg) 110 (118) ı 65 (65)
... ı kg R410A ı 1,72
l
integrated: • yes — no
up to °C ı up to °C — I —
l
W
bar
... ı A 3~PE/400V/50Hz ı C10
... ı A 1~N/PE/230V/50Hz ı B10
... ı A 3~N/PE/400V/50Hz ı B16
... ı A — ı —
kW ı A ı ... 1,57 ı 3,02 ı 0,75
A ı kW 6,01 ı 3,10
A ı A 30,0 ı —
IP
kW 9 ı 6 ı 3
min. — max. W ı W 2 – 60 ı 3 – 140
— I —
— I —
integrated: • yes — no
integrated: • yes — no
813467a
SWC 102(H)(K)3
9,34 ı 5,05
8,84 ı 3,80
8,30 ı 2,82
11,19 ı 6,30
7 8,6
20 I 60 20 I 60
-5 – 25 -5 – 25
B0W65 B0W65
31 32
43 44
1500 ı 2200 ı 3300
0,93 (0,86) ı 2200
• I • I • I •
-13 -13
3 3
800 ı 1600 ı 2000
0,52 (0,48) ı 1600
— (—) ı —
3 3
180 (188)
115 (123) ı 65 (65)
R410A ı 1,98
— —
— —
— I —
— —
— —
— —
3~PE/400V/50Hz ı C10
1~N/PE/230V/50Hz ı B10
3~N/PE/400V/50Hz ı B16
— ı —
1,87 ı 3,73 ı 0,72
7,63 ı 4,00
— ı 22,0
20 20
9 ı 6 ı 3
2 – 60 ı 2 – 180
— I —
— I —
• I • • I •
• I • • I •
813468a
25
