Technical data / Scope of supply

Performance data: Heating output / COP
Heating capacity ı COP
Cooling capacity at max. flow rate (B15/W25), units with passive cooling: Identifier K
Limits of use
Heating circuit return min. I Heating circuit flow max.
Heat source return
additional operating points
Sound
Sound pressure level at 1m distance from edge of unit
Sound power level to EN12102
Heat source
Flow rate: minimum I nominal analogous to B0/W35 I maximum
Max. free heat pump pressure ∆p (with cooling ∆pK) ***) ı Flow rate
Approved anti-freeze
Anti-freeze concentration: Minimum frost protection down to
max. allowable operating pressure
Heating circuit
Flow rate: minimum I nominal analogous to B0/W35 I maximum
Max. free heat pump pressure ∆p (with cooling ∆pK) ı Volume flow
Pressure losses, heat pump ∆p ı Volume flow
max. allowable operating pressure
General unit data
Total weight (with cooling)
Box weight (with cooling) ı Tower weight (with cooling)
Refrigerant type ı Refrigerant capacity
Domestic hot water tank
Net volume
Impressed current anode
Domestic hot water temperature, heating pump mode I Electric heating element
Mixed water quantity according to ErP: 2009/125/EC (at 40°C, draw-off of 10 l/min)
Standing loss according to ErP: 2009/125/EC (at 65°C)
Maximum pressure
Electrics
Voltage code ı all-pole heat pump fusing *)**)
Voltage code ı Control voltage fusing **)
Voltage code ı Electric heating element fusing **)
Voltage code ı all-pole fusing for connection via a joint supply cable*)**)
WP*): effect. Power input at B0/W35 to EN14511 I Current input I cosφ
WP*): Max. machine current I Max. power input within the limits of use
Starting current: direct ı with soft starter
Degree of protection
Electric heating element output
Circulation pump power consumption, heating circuit I heat source
Other unit information
Safety valve, heating circuit I Heat source
Expansion valve, heating circuit I Heat source
Overflow valve I Changeover valve, heating -Domestic hot water
Vibration isolators, heating circuit I Heat source
*) Only compressor, **) Follow local regulations, ***) Figures for 25% mono-ethylene glycol
24
Subject to change without notice | 83056700fUK – Translation of the original operating manual | ait-deutschland GmbH
at B0/W35 operating point to EN14511
at B0/W45 operating point to EN14511
at B0/W55 operating point to EN14511
at B7/W35 flows analogous to B0/W35
Monoethylene glycol I Propylene glycol I Methanol I Ethanol
kW ı COP
kW ı COP
kW ı COP
kW ı COP
min. I max.
dB(A)
dB(A)
bar (bar) ı l/h
bar (bar) ı l/h
bar ı l/h
kg (kg)
kg (kg) ı kg (kg)
... ı kg
integrated: • yes — no
up to °C ı up to °C
kW ı A ı ...
A ı kW
A ı A
min. — max. W ı W
included in scope of supply: • yes — no
included in scope of supply: • yes — no
integrated: • yes — no
integrated: • yes — no

SWC 42(H)(K)3

SWC 42(H)(K)3
4,70 ı 4,70
4,42 ı 3,42
4,16 ı 2,58
5,83 ı 5,70
kW 4,3
°C 20 I 60
°C -5 – 25
... B0W65
31
43
l/h 700 ı 1050 ı 1575
0,75 (—) ı 1050
• I • I • I •
°C -13
bar 3
l/h 450 ı 850 ı 1300
0,71 (0,69) ı 850
— (—) ı —
bar 3
155 (163)
90 (98) ı 65 (65)
R410A ı 1,05
l —
—
— I —
l —
W —
bar —
... ı A 3~PE/400V/50Hz ı C10
... ı A 1~N/PE/230V/50Hz ı B10
... ı A 3~/N/PE/400V/50Hz ı B16
... ı A — ı —
1,00 ı 2,44 ı 0,59
4,8 ı 2,3
22,0 ı —
IP 20
kW 9 ı 6 ı 3
2 – 60 ı 5 – 87
— I —
— I —
• I •
• I •
813465a
