DMP Electronics EBOX-3350DX2-AP User Manual

Hide thumbs Also See for EBOX-3350DX2-AP:
Table of Contents

Advertisement

Quick Links

See also: User Manual
EBOX-3350DX2-AP
User's Guide
DMP Electronics Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EBOX-3350DX2-AP and is the answer not in the manual?

Questions and answers

Related Manuals for DMP Electronics EBOX-3350DX2-AP

Summary of Contents for DMP Electronics EBOX-3350DX2-AP

  • Page 1 EBOX-3350DX2-AP User’s Guide DMP Electronics Inc.
  • Page 2 No part of this manual may be reproduced, copied, translated or transmitted, in whole or in part, in any form or by any means without the prior written permission of the DMP Electronics Inc. Copyright 2018 DMP Electronics Inc.
  • Page 3 EBOX-3350DX2-AP User Manual Trademarks Acknowledgment is the registered trademarks of DMP Electronics Inc. Other brand names, product names or trade names appearing in this document are the properties and registered trademarks of their respective owners. All names mentioned herewith are served for identification purpose only.
  • Page 4 EBOX-3350DX2-AP User Manual Safety Information WARNING  Do not expose EBOX-3350DX2-AP to rain or moisture, in order to prevent shock and fire hazard.  Never install EBOX-3350DX2-AP in wet locations.  Do not open the cabinet to avoid electrical shock. Refer to your nearest dealer for qualified personnel servicing.
  • Page 5 DMP Electronics Inc.
  • Page 6 DMP and Users in pursuant of trading. Product Description: With this product, herewith also known as EBOX-3350DX2-AP, which is a simplified & an economical design of an embedded device for Special Purpose Personal Computing. The basic specification of this product is comprised of the x86 technology, design, and with onboard 512 MB DDR2 System memory, VGA display, USB ports and LAN Interfaces.

  • Page 7: Table Of Contents

    EBOX-3350DX2-AP User Manual Contents Chapter 1 02 Unpacking your EBOX-3350DX2-AP Mini PC Chapter 2 05 EBOX-3350DX2-AP Overview 06 System Specifications 07 Peripherals Connecting Chapter 3 10 BIOS Reconfiguring 11 Linux Installation Guide Chapter 4 20 Technical Specifications Chapter 5 22 Onboard Connectors Summary...
  • Page 8 EBOX-3350DX2-AP User Manual Chapter DMP Electronics Inc.

  • Page 9: Unpacking Your Ebox-3350Dx2-Ap Mini Pc

    EBOX-3350DX2-AP User Manual Unpacking Your EBOX-3350DX2-AP Mini PC Congratulation! You have just acquired EBOX-3350DX2-AP, please check the following items: Packing List: Q’ty Item No. Description EBOX-3350DX2-AP Mini PC 75 x 75mm to 100 x 100mm VESA mounting rack (Optional) Note: The accessories are subject to change without immediate notice.
  • Page 10 The EBOX-3350DX2-AP is a revolutionary device which is especially designed for limited physical space and temperature concerns. No matter you are in a jammed office, a crowded place, or public transportation, it can be easily integrated with a VESA LCD to bring you EBOX-3350DX2-AP access at any time.
  • Page 11 EBOX-3350DX2-AP User Manual Chapter DMP Electronics Inc.

  • Page 12: Ebox-3350Dx2-Ap Overview

    EBOX-3350DX2-AP User Manual EBOX-3350DX2-AP Overview Front Panel A: Power LED The power LED lights up when the system is turned on. B: Audio Line Out Audio output to speaker. C: Audio Mic In For Microphone input. D: USB 2.0 port Connection for external USB devices.

  • Page 13: System Specifications

    1. USB 2.0 x 3 (2 at front, 1 at rear) 2. SD Card slot x 1 3. Audio (Mic In, Line Out) Dimension & Weight EBOX-3350DX2-AP 95 x 95 x 20mm/ 277g Power consumption DC +5V@1.1A DMP Electronics Inc.

  • Page 14: Peripherals Connecting

    User Manual Peripherals Connecting the Power Adaptor A: Micro 5pin USB DC Power Jack To use EBOX-3350DX2-AP please attach the USB cable or spec in +5V@2A AC adapter for the power source. Note: Unit with Auto Power On support function, it will turned on automatically after power adaptor plug on.
  • Page 15 EBOX-3350DX2-AP User Manual Peripherals Connecting the USB EBOX-3350DX2-AP provides 3 external USB ports (2 at front, 1 at rear). C: SD Card Slot For booting device by SD Card. D: Microphone/ Earphone The EBOX-3350DX2-AP supports Microphone Input and Speaker Output E: USB 2.0 port...
  • Page 16 EBOX-3350DX2-AP User Manual Chapter DMP Electronics Inc.

  • Page 17: Bios Reconfiguring

    EBOX-3350DX2-AP User Manual BIOS Reconfiguring AMI BIOS is used in the EBOX-3350DX2-AP. To reconfigure the EBOX-3350DX2-AP, press the <Del> key after power turn on to enter the BIOS setup main menu. Select from the menu, the desired setup to change.
  • Page 18 Linux installation For Debian7.0/ Ubuntu10.04 Regarding the system installation of Debian7.0/ Ubuntu10.04, please follow the steps and suggestions to complete the system installation on the EBOX-3350DX2-AP platform. There we provided is a brief instruction to assist clients, and user can configure it by themselve according to their needs.
  • Page 19  Then the system would inform you that multiple network interfaces were detected on the EBOX-3350DX2-AP, and the user to choose the one as primary network interface, both of them all could be chosen. And the Ethernet cable must be plugged in this period.
  • Page 20 Debian desktop environment and standard system utilities, then to continue following procedure. It would start the package installation, around hundred packages would be installed, please be patient until system informed you for the next step. DMP Electronics Inc.
  • Page 21 MBR area? Answer YES and wait system to complete the installation as last procedure.  When it's completed, the disc tray will eject and inform you, then press continue to restart and be ready to enjoy the new system! The Debian7.0 The Ubuntu10.04 DMP Electronics Inc.
  • Page 22 2.6.34.10 to boot when GRUB boot loader was loaded. You can keep pressing the key “Shift” when the system from booting, then the boot loader would show the option of kernel for you. Then find the “Ubuntu, With Linux 2.6.32-21- vortex86” to execute. DMP Electronics Inc.
  • Page 23 User Manual  Or you can remove the default kernel 2.6.32-??-generic that be arranged as a higher priority than the kernel we installed for the EBOX-3350DX2-AP platform, with the instruction below through the terminal.  First, check what version be installed as default in the system: # grep –w linux-image-2.6.32 /var/log/dpkg.log...
  • Page 24 The supported resolutions: 1920x1200 (16:10) 1400x960 1280x768 (16:10) 1920x1080 (16:9) 1280x1024 (5:4) 1280x720 (16:9) 1600x1200 (4:3) 1440x900 (16:10) 1024x768 (4:3) 1680x1050 (16:10) 1280x960 (4:3) 800x600 (4:3) 1400x1050 (4:3) 1366x768 (16:9) 640x480 (4:3) 1440x960 (3:2) 1360x768 (16:9) DMP Electronics Inc.
  • Page 25 Set the Log in as “user account” automatically. Disable the power saving mode when system idle, System / Preference / Screensaver Unmarked the option “Active the screensaver when computer is idle”. Now, it is a workable Linux system for your EBOX-3350DX2-AP. DMP Electronics Inc.
  • Page 26 EBOX-3350DX2-AP User Manual Chapter DMP Electronics Inc.

  • Page 27: Technical Specifications

    CE, FCC, VCCI Optional Internal SD Card slot Remark: 1. SD Card slot x 1 (Bootable but hot-swappable not support). 2. “AP” indicated Auto Power On supported feature, system will turned on automatically after power adapter is plug on. DMP Electronics Inc.
  • Page 28 EBOX-3350DX2-AP User Manual Chapter DMP Electronics Inc.

  • Page 29: Onboard Connectors Summary

     Front Connectors Outline A: Power LED B: Line out C: Mic in D: USB 2.0 E: SD Card Slot  Rear Connectors Outline F: USB 2.0 G: VGA H: RJ-45 LAN I: Micro 5pin USB DC Power Jack DMP Electronics Inc.

  • Page 30: Pin Assignments

    J10: USB 2.0 (90 Pin # Signal Name Data -- Data + J12: LAN: RJ-45 connector Pin # Signal Name Pin # Signal Name FTXD+ FTXD- FRXIN+ FRXIN- LEDS: POWER ON/ OFF LED Color State Green Power On DMP Electronics Inc.
  • Page 31 EBOX-3350DX2-AP User Manual Chapter DMP Electronics Inc.

  • Page 32: Taking Care Of Your Ebox-3350Dx2-Ap

    3350DX2-AP uses high-frequency radio signal and may interface with radio or TV reception causing interference or poor signal display. When this happens, relocate the EBOX-3350DX2-AP by a suitable distance away from it. Do not drop the EBOX-3350DX2-AP from working table nor place heavy objects on top of it. DMP Electronics Inc.
  • Page 33 User Manual Cleaning Your EBOX-3350DX2-AP Clean EBOX-3350DX2-AP with a soft, dry cloth or a soft cloth lightly moistened with a mild detergent solution. Do not use any type of abrasive pad, scouring powder, or solvent such as alcohol or benzene, as these may damage the finish of EBOX-3350DX2-AP.

  • Page 34: Troubleshooting

    EBOX-3350DX2-AP for at least one hour. When you have checked all the above guidelines and the EBOX-3350DX2-AP does not work. Remove the power from the EBOX-3350DX2-AP, unplug the power cable, and plug it in again. B. BIOS Error Message –...
  • Page 35 Follow the steps as written in item B. BIOS error message. If you have just connected EBOX-3350DX2-AP to a CD/ DVD or USB Drivers, remove these peripherals. And restart to confirm that the Windows operating system starts properly. If EBOX- 3350DX2-AP continues to display the message ”Operating system not found,”...
  • Page 36 EBOX-3350DX2-AP User Manual Chapter DMP Electronics Inc.

  • Page 37: Terms And Condition

    The Purchaser must pre-pay shipping for any defective system or parts returned under the warranty. DMP Electronics Inc. shall not be liable for risk of loss or damage during shipment of your returned system or parts if you fail to insure the shipment.
