DMP Electronics EBOX-3350DX2-AP User Manual

Hide thumbs Also See for EBOX-3350DX2-AP:
Table of Contents

Advertisement

Quick Links

EBOX-3350DX2 Series
EBOX-3350DX2
EBOX-3350DX2-AP
EBOX-3350DX2-C2
EBOX-3350DX2-C2AP
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EBOX-3350DX2-AP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DMP Electronics EBOX-3350DX2-AP

Summary of Contents for DMP Electronics EBOX-3350DX2-AP

  • Page 1 EBOX-3350DX2 Series EBOX-3350DX2 EBOX-3350DX2-AP EBOX-3350DX2-C2 EBOX-3350DX2-C2AP User’s Guide...
  • Page 2 Copyright 2014 DMP Electronics Inc. Special Notice to Users DMP Electronics Inc. provides no warranty with regard to this manual, the software, or other information contained herein and hereby expressly disclaims any implied warranties of merchantability or fitness for any particular purpose with regard to this manual, the software, or such other information.
  • Page 3 Trademarks Acknowledgment The EBOX-3350DX2 Series is the registered trademarks of DMP Electronics Inc. Microsoft, Windows, and AMI are registered trademarks of Microsoft Corporation and American Megatrends Inc. in the United States and/ or other countries respectively. Other brand names, product names or trade names appearing in this document are the properties and registered trademarks of their respective owners.

  • Page 4: Safety Information

    Safety Information WARNING  Do not expose EBOX to rain or moisture, in order to prevent shock and fire hazard.  Never install EBOX in wet locations.  Do not open the cabinet to avoid electrical shock. Refer to your nearest dealer for qualified personnel servicing.
  • Page 5 Regulatory FCC Class A Note This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 6: Product Description

    Purchase Agreement Purpose: In accordance to the general commercial conduct of Trust and Fair Trade, herewith below is the agreement for the protection for both parties, DMP and Users in pursuant of trading. Product Description: With this product, herewith also known as EBOX-3350DX2 Series, which is a simplified & an economical design of an embedded device for Special Purpose Personal Computing.

  • Page 7: Table Of Contents

    Contents Chapter 1 02 Unpacking your EBOX Mini PC Chapter 2 05 EBOX-3350DX2 Series Overview 06 System Specifications 07 Peripherals Connecting Chapter 3 10 BIOS Reconfiguring 11 Linux Installation Guide Chapter 4 20 Technical Specifications Chapter 5 22 Onboard Connectors Summary 24 Pin Assignments Chapter 6 27 Taking Care Your EBOX VESA PC...
  • Page 8 Chapter...

  • Page 9: Unpacking Your Ebox Mini Pc

    Unpacking Your EBOX Mini PC Congratulation! You have just acquired EBOX-3350DX2 Series, please check the following items: Packing List: Q’ty Item No. Description EBOX-3350DX2 Series VESA PC 75 x 75 mm to 100 x 100 mm VESA mounting rack (Optional) Note: The accessories are subject to change without immediate notice.
  • Page 10 Preface EBOX-3350DX2 Series: VESA PC The EBOX-3350DX2 Series is a revolutionary device which is especially designed for limited physical space and temperature concerns. No matter you are in a jammed office, a crowded place, or public transportation, it can be easily integrated with a VESA LCD to bring you EBOX-3350DX2 Series access at any time.
  • Page 11 Chapter...

  • Page 12: Ebox-3350Dx2 Series Overview

    EBOX-3350DX2 Series Overview Front Panel A: Reset Button For system reset or turn on. (Available in 3350DX2/ 3350DX2-C2). B: Power LED The power LED lights up when the system is turned on. C: Audio Line Out Audio output to speaker. D: Audio Mic In For Microphone input.

  • Page 13: System Specifications

    System Specification Operating System Vortex86DX2 (933MHz) Windows XP Embedded Windows Embedded CE Main Memory 512MB DDR2 (32-bit DRAM bus) Supported Linux Distribution list: BIOS 1. Gentoo 4.2 AMI BIOS 2. Ubuntu 8.04 3. Ubuntu 8.10 4. Ubutnu 9.04 Resolution up to 1920 x 1440 High Colors 5.

  • Page 14: Peripherals Connecting

    Peripherals Connecting the Power Adaptor A: DC Power Jack To use EBOX-3350DX2 Series immediately, please attach the USB cable or supplied AC adapter for the power source. Note: With the Auto Power On support function (Optional), the system then will be turned on automatically.
  • Page 15 Peripherals Connecting the USB EBOX-3350DX2 series provides 3 external USB ports (2 at the front, 1 at the rear). C: SD Slot For booting device by SD Card. D: Microphone/ Earphone The EBOX-3350DX2 Series supports Microphone Input and Speaker Output E: Reset Button For system reset or turn on Note: Models with Auto Power On feature has...
  • Page 16 Chapter...

  • Page 17: Bios Reconfiguring

    BIOS Reconfiguring AMI BIOS is used in the EBOX-3350DX2 Series. To reconfigure the EBOX-3350DX2 Series, press the <Del> key after power turn on to enter the BIOS setup main menu. Select from the menu, the desired setup to change. Press <Esc> to go back to main menu. Press <F9>...
  • Page 18 Linux installation For Debian7.0/ Ubuntu10.04 Regarding the system installation of Debian7.0/ Ubuntu10.04, please follow the steps and suggestions to complete the system installation on the EBOX-3350DX2 Series platform. There we provided is a brief instruction to assist clients, but you can configure it by yourself with system’s asking.
  • Page 19 2. Basic system installation  For Debian7.0, after booting from the installation CD, moving straight to install system would get a text only system, please choose Graphic Install if GUI is necessary for your application.  The system would start to ask questions for basic configuration. Such as the language, keyboard map and time zone, etc.
  • Page 20  As installation processing, the system would need you to make decisions about how the partitions your disk for the system? Following default option is using entire disk for the beginner. Choose “all files in one partition”. Other allocation is also available, depends on customers’...
  • Page 21  The next question is about the agreement of the installation of the GRUB boot loader to the MBR area? Answer YES and wait system to complete the installation as last procedure.  When it's completed, the disc tray will eject and inform you, then press continue to restart and be ready to enjoy the new system! The Debian7.0 The Ubuntu10.04...
  • Page 22 3. Kernel and graphic driver installation Install the Kernel Package (Console mode)  For Debian7.0, you can skip this procedure for kernel installation; Because system could work with default kernel version (3.2.0).  Clicking the icon of the terminal from the application. And download the kernel 2.6.32-21 from below link then to store the kernel package.
  • Page 23  Or you can remove the default kernel 2.6.32-??-generic that be arranged as a higher priority than the kernel we installed for the EBOX-3350DX2 platform, with the instruction below through the terminal.  First, check what version be installed as default in the system: # grep –w linux-image-2.6.32 /var/log/dpkg.log ...
  • Page 24 Install the VGA driver (Console mode)  Switch to console mode by pressing key <Ctrl> + <Alt> + <F1>, then copy the VGA driver rdc_drv.so to the driver folder /usr/lib/xor/modules/drivers/, before that, you can download the driver from links below for Debian7 and Ubuntu10.04 individually. The Ubuntu10.04 Xorg Version is 1.7.6 The Debian 7.0 Xorg Version is 1.12.4 VGA Driver (click...
  • Page 25 4. The system configuration Enable the Auto login System / Administration / Login Screen Execute the utility “Login Screen” and enter the password to process it. Set the Log in as “user account” automatically. Disable the power saving mode when system idle, System / Preference / Screensaver Unmarked the option “Active the screensaver when computer is idle”.
  • Page 26 Chapter...

  • Page 27: Technical Specifications

    2. Power Supply 10W Micro USB EU and US Type offer to sell as extra spare parts. EBOX-3350DX2 Series Models Listing: EBOX-3350DX2: Standard Version. EBOX-3350DX2-AP: Standard Version with Auto Power On Support. EBOX-3350DX2-C2: Standard Version with RS-232 port x 2. EBOX-3350DX2-C2AP: Standard Version with RS-232 port x 2 & Auto Power On Support.
  • Page 28 Chapter...

  • Page 29: Onboard Connectors Summary

    Onboard Connectors Summary Summary Table for CPU Board Description Type of Connections Pin nbrs. D-Sub Connector 15-pin DC +5V Input Mini USB Jack 1-pin Line out Audio Jack 2-pin Mic in Audio Jack 2-pin USB (Front) USB Connector 8-pin USB (Front) USB Connector 8-pin USB (Back)
  • Page 30  Rear Connectors Outline EBOX-3350DX2/ AP REAR LOOK G: USB V2.0 H: VGA I : RJ-45 LAN J : DC Power Jack EBOX-3350DX2-C2/ C2AP REAR LOOK K: RS-232 Port *Only Available in EBOX-3350DX2-C2/ 3350DX2-C2AP...

  • Page 31: Pin Assignments

    Pin Assignments J3: VGA – 15-pin D-Sub Connector Pin # Signal Name Pin # Signal Name Pin # Signal Name HYSYNC VSYNC J4: Mini USB DC Power Input Pin # Signal Name +5V Input USB In - USB In + None J7, J8: USB : For connection to external USB device –...
  • Page 32 Pin Assignments J12: LAN: RJ-45 Connector Pin # Signal Name Pin # Signal Name FTXD+ FTXD- FRXIN+ FRXIN- J13, J14: COM - 9-pin D-Sub Connector Signal Signal Pin # Pin # Name Name LEDS: POWER ON/ OFF LED Color State Green Power On...
  • Page 33 Chapter...

  • Page 34: Taking Care Your Ebox Vesa Pc

    Taking Care of your EBOX This section gives you some guidelines on using EBOX-3350DX2 Series – Safe using, Storing and Handling. Storing Do not place EBOX-3350DX2 Series in a location that is subject to:  Heating sources, such as stove, oven, heater, radiator or air duct. ...
  • Page 35 Using Cables for Connection To avoid the problem, use only the specified interface cables in your accessory bag. The supplier will not be responsible for the connection arising from the other unspecified peripheral equipment. Do not use cut or damaged cables for connection. Cleaning Your VESA PC Clean the VESA PC with a soft, dry cloth or a soft cloth lightly moistened with a mild detergent solution.

  • Page 36: Troubleshooting

    Troubleshooting This section describes the techniques of resolving some basic problems that you encounter when using EBOX-3350DX2 Series. For more troubleshooting guidelines, please contact your nearest dealer for technical support. Troubleshooting Your VESA PC A. VESA PC does not start – Make sure the EBOX-3350DX2 Series is properly secured and plugged into a power source before it is turned on.
  • Page 37 Go to “Exit” menu using the Direction keys <↑↓> and choose the option “Load Optimal Defaults”, then press <Enter>. A message dialog appears as seen below, hit “Y” key and presses <Enter> to save and recover to the factory setting. “Load Optimal Defaults (Y/N)? Y”...
  • Page 38 Chapter...

  • Page 39: Terms And Condition

    The Purchaser must pre-pay shipping for any defective system or parts returned under the warranty. DMP Electronics Inc. shall not be liable for risk of loss or damage during shipment of your returned system or parts if you fail to insure the shipment.
