Section 4 Maintenance
Other Omeratipns
DOORS/H
NGES
Over time and with heavy-use doors, the hinges may
become loose. If this happens, tighten the screws that
mount the hinge brackets to the frame of the unit. Loose
or sagging doors can cause the hinges to pull out of the
frame, which may damage both the doors and the hinges.
In some cases this may require qualified service agents or
maintenance personnel to perform repairs.
Dppr AdjustIent
If the door needs lowering at the handle, use a 5/16" (8mm)
wrench to loosen the hinge screws and install a spacer
outside of the hinge. Tighten the screws.
If the door needs to be higher at the handle, use a 5/16"
(8mm) wrench to loosen the hinge screws and install a
spacer inside of the hinge. Tighten the screws.
Part Number 020007115 06/27/2019 33
