progressive automations FLT-09 User Manual page 7

06
STEP 6
Place the assembled three-leg frame onto the
underside of your tabletop. Adjust the width of the frame
to fit your tabletop by sliding the two halves apart.
We recommend leaving at least 1.25" of the tabletop
extending beyond the assembled frame. Make sure
to center the Side Brackets (3).
STEP 7
If your tabletop has pre-drilled holes, skip ahead to Step
8. If not, lock the position of the Center Rails using eight
of the M6x10 Machine Screws (10). Make sure the
screws make contact with the Center Rails (6) by sliding
them as needed.
STEP 8
Ensure that the wood screws are not too long for
your tabletop.
If possible, pre-drill pilot holes to ease the installation
process. Attach the frame to the tabletop using four of
the M6x16 Wood Screws (12).
Attach the hand remote so the front of the remote is
lined up with the tabletop edge. Place the remote
anywhere along the edge so that you'll have easy
access to it. Use two of the M6x20 Wood Screws (13) to
attach and secure the remote to the tabletop. Do not
over-tighten the screws as this could cause damage to
the components.
STEP 9
Connect the cable from each Leg (1) directly into the
control box. Use cable extenders when necessary.
Then connect the hand remote cable to the control box.
Use the adhesive-backed cable clips to secure the
cables so they are not loose and in the way.
STEP 10
We recommend having two people for this step. Flip
the fully assembled desk by the legs (not by the
tabletop).
IMPORTANT
Prior to normal operation, please complete a Reset
Procedure outlined in the next section.
Assembly
