  • Page 1: Table Of Contents

    FLT-05 User Manual Contents Page 2 Caution/Liability Page 3 Parts Page 4 Technical Specifications Assembly Instructions Page 5-6 Operational/Reset Procedure, Page 7 Troubleshooting Dimensions Page 8...
  • Page 2 Caution Liability...

  • Page 3: Technical Specifications

    Technical Specifications Input Voltage 120 VAC, 60 Hz Output Voltage 24 VDC Stroke 25.5" Weight Capacity 330 lbs (110 lbs Per Leg) Speed 1.50"/sec Height Range 23.5” - 49” (without table top) Duty Cycle 10% Max. 2 mins on, 18 mins off Material Steel Certification...
  • Page 4 Parts Rubber Frame 2 Side Bracket x3 Frame 3 Frame 1 Foot x3 Block Wood Screw Wood Screw Caster Center Rail x4 Cable Clip x16 ST5x16 ST5x20 Machine Screw Machine Screw Control Box Handset Power Cord Cable (1.3m) M6x10 M6x14...

  • Page 5: Assembly Instructions

    Assembly Instructions STEP 1 STEP 3 Place one of the Legs (9) into the Frame 3 (5) and Frame 1 (2) should be placed on the side of the desk line up the holes. Using the supplied Allen Wrench, where you are planning to mount the Control Box (15). insert four M6x10 Machine Screws (13) through the Slide the Control Box into the Frame (2) holes in the Frame (5), going through into the Leg (9)
  • Page 6 Assembly Instructions STEP 5 STEP 7 Using four M6x10 Machine Screws (13), link the Attach each Foot (6) with four M6x14 Machine assembled Frame 2 (3) and Frame 1 (2) as shown in Screws (14) and tighten them in a cross-pattern. the image below.

  • Page 7: Operational/Reset Procedure

    Operational Procedure Once your table lift is installed, operation is simple. Using the wired remote will allow full control over extending and retracting the lift columns. Use the up button to raise the table lift and the down button to lower the table lift. You can program up to 4 locations using the memory setup: Use the up/down buttons on the remote to find your desired height(s), then press “M”...

  • Page 8: Dimensions

    Dimensions 22.6" 2" 49" 23.5" 1.2" 27.5" 70.9" 40.1"...
