FLT-01
User Manual
The FLT-01 is a single leg table lift set with an 18.1" stroke size and 175 lbs
of force. This model includes a power supply, remote for an interactive up/
down motion control, and a table top so you have everything you need for
your ideal height adjustable table.
Contents
Page 2
Page 2
Page 3
Page 3
Page 4
Page 5-6
Advertisement
Table of Contents
Related Manuals for progressive automations FLT-01
Summary of Contents for progressive automations FLT-01
-
Page 1: Table Of Contents
FLT-01 User Manual The FLT-01 is a single leg table lift set with an 18.1” stroke size and 175 lbs of force. This model includes a power supply, remote for an interactive up/ down motion control, and a table top so you have everything you need for your ideal height adjustable table. -
Page 2: Caution/Information
Caution/Information Use/Liability... -
Page 3: Technical Specifications
Technical Specifications Height Range 26.6” - 44.7” Base Width 43” min. - 72.4” max. Minimum Table Top Size 43"x 24” Travel Speed 0.8" per second (varies, slowest w/ max load) 180 lbs. Weight Capacity Duty Cycle 10% Max. 2 mins on, 18 mins off Features Soft start/stop Adjustable leveling studs... -
Page 4: Parts
Parts... -
Page 5: Assembly Instructions
Assembly Instructions STEP 1 Lay out all the included components and hardware to ensure you have everything listed on the parts page. Take the Lifting Column (P3) and place it upside down. Then slide the Base Column (P2) over the Lifting Column (P3) until it is fully inserted. - Page 6 Assembly Instructions STEP 6 Attach the Remote (P4) to the underside of the desktop with the four M5x16 Pan Head Wood Screws (P12). Then connect the Remote (P4) to the Power Supply (P5) using the Cable (P7). Finally connect the Power Cord (P6) to the Power Supply (P5).
