- Page 1 FLT-03-2-2 User Manual Contents Page 2 Caution/Liability Page 3 Technical Specifications Page 4 Parts Page 5 Operational/Reset Procedure, Troubleshooting Page 6 Dimensions...
- Page 2 Caution Liability...
-
Page 3: Technical Specifications
Technical Specifications Input Voltage 120 VAC, 60 Hz Output Voltage 24 VDC Stroke 16" Weight Capacity 880 lbs (440lbs Per Columns) Speed 0.5"/sec Height Range 22” - 38” Duty Cycle 10% Max. 2 mins on, 18 mins off Material Steel Certification Features Soft start/stop, adjustable leveling studs &... - Page 4 Parts Control Box and Remote Lifting Columns x 2 AC Power Cord Setup FLT-03-2-2 FLT-03-2-2 LIFTING COLUMN [M2] LIFTING COLUMN [M1] 110/240VAC FLT-03-2-2 CONTROL BOX WIRED REMOTE...
-
Page 5: Troubleshooting
Once the button is released, the FLT-03-2-2 will stop moving. You can program up to 4 locations using the memory setup: Use the up/down buttons on the remote to find your desired height(s), then press “M”... - Page 6 Dimensions Legs 7.9" 0.3" 0.8" 3.9" 4.4" 0.5" Remote 3.3" 3.3" 6.7" 1.4" 0.2" 3.4" 2.0" ˄ ˅ 3.8" Ø0.5" 5.7" 2.2" 0.5" 2.5" 4.4" 7.9" Ø0.2" 0.3" 1.4" 3.2" Control Box 1.6" 0.7" 3.5" 3.5" 0.3" 0.1" 10.1"...
