Summary of Contents for progressive automations FLT-04

  • Page 1: Table Of Contents

    FLT-04 User Manual Contents Caution/Liability Page 2 Technical Specifications Page 3 Parts Page 4 Assembly Instructions Page 5 Setup Page 6 Operational/Reset Procedure, Page 7 Troubleshooting Dimensions Page 8-9...

  • Page 2: Caution/Liability

    Caution Liability...

  • Page 3: Technical Specifications

    Technical Specifications Input Voltage 120 VAC, 60 Hz Output Voltage 24 VDC 25.5" Stroke Weight Capacity 700lbs (175 lbs Per Leg) Speed 1.50"/sec 23.5” - 49” (without table top) Height Range Duty Cycle 10% Max. 2 mins on, 18 mins off Material Steel Certification...

  • Page 4: Parts

    Parts Wood Screw Wood Screw Stand-Off Control Box M5x16 M5x20 Glide (Prenstalled) x4 LC Cable (59") Cable Clip Switch Power Cable Noise Attenuation Machine Screw VT Bracket M6x14...

  • Page 5: Assembly Instructions

    Assembly Instructions STEP 1 Ensure the box and remote are placed so the Lay out all the included components and hardware wires can reach between everything to ensure you have everything listed on the parts page. Take four of the self-adhesive Noise Attenuation Pads (P5) and place them on the VT Brackets (P4) as shown.

  • Page 6: Setup

    Setup FLT-04 Leg FLT-04 Leg [M2,M4] [M1,M3] 110VAC FLT-04 CONTROL BOX WIRED REMOTE...

  • Page 7: Operational/Reset Procedure

    Operational Procedure Once your lift columns are installed, operation is simple. Using the wired remote will allow full control over extending and retracting the lift columns. Use the up button to raise the column lifts and the down button to lower the column lifts.

  • Page 8: Dimensions

    Dimensions Legs 1.0" 0.5" 2.0" 3.2" 22.0" 1.7" M6X10 0.5" 6.5" 3.8" 7.0" Brackets 7.1" Stand-Offs 0.1" Ø0.25" 0.1" 1.9" 1.0" 0.6" 6.4" 0.6" 6.1" 1.4" 0.8" 2.8" 1.6" 1.9" Ø0.20" 0.1" Ø0.4" 5.1" 7.1" 2.8" 2.4" 6.5" Ø1.8" 0.4" 3.5"...
  • Page 9 Dimensions Control Box 1.8" 0.6" 0.5" 5.8" 0.6000 Ø0.2 5.8" 10.1" Wired Remote 3.3" 1.4" 0.2" 3.4" 2.0" ˄ ˅ 5.7" 2.2"...
