5-1. Setting Items of the Primary Station

J : NAME STYLE

Purpose
This menu is used to switch the name styles of the destina-
tion and source.
The "Type + Number" name (Type + Num) or "Descrip-
tion" name (DESCRIP. NAME) can be set.
Names on the setting screen of menu items [C], [D], [E],
[H], [L], [M], [N], [O], and [Q] are switched according to
this menu.
Setting Procedure
1. Select menu item [J].
2. Press the alphabet key [J] and [Enter]. The message
on the screen will change from "Type + Num" to
"DESCRIP. NAME" each time this key are pressed.
. . . . . Destination name setting procedure using the
Description name
3. Set menu item [J] to the Description name mode.
Ex. [J : NAME STYLE (DESCRIP. NAME)]
4. Select menu item [C].
5. Move the cursor to the desired destination number.
6. When either [Enter] is pressed, the destination name
can be typed. If the Description name is set already,
delete it by [BS].
7. Enter the Description name using the alphabet keys or
the numerical keys. When [Enter] is pressed, the
Description name will be set.
n
Up to sixteen characters can be input. Remote control
units except BKS-R3281 will display until the seven
characters. As the first seven characters are also used to
distinguish the names, the unit may not operate properly if
the same names are assigned for the first seven characters.
DESTINATION NUMBER TRANSCODE
1.....7.........
001=OUT001 P DST-012
003=OUT003 London
005=OUT005 New York
007=OUT007 Toront
009=OUT009
011=OUT011 Net-2
013=OUT013 EDIT-5
015=OUT015 CG-B
017=OUT017 P OUT017
019=OUT019 Washington D.C. | 020=OUT020
021=OUT021 OUT021
023=OUT023 OUT023
025=OUT025 OUT025
027=OUT027 OUT027
029=OUT029 Atlantic Ocean
031=OUT031 OUT031
F1:SEARCH F2:JUMP F3:PgUp F4:PgDn F5:PASTE Ctrl-E:RETURN TO MENU
Example of Destination Name Setting Screen
5-10
DVS-V6464B V2.10 STATION NUMBER 1
1.....7.........
| 002=OUT002 Hong Kong |
| 004=OUT004 P Market |
| 006=OUT006 P Tokyo |
| 008=OUT008 OUT008 |
| 010=OUT010 P Net-1 |
| 012=OUT012 EDIT-2 |
| 014=OUT014 CG-A |
| 016=OUT016 News-1 |
| 018=OUT018 Mountain |
OUT020 |
| 022=OUT022 |
| 024=OUT024 River |
| 026=OUT026 OUT026 |
| 028=OUT028 OUT028 |
| 030=OUT030 OUT030 |
| 032=OUT032 OUT032 |
Operating Function Keys
[F1] : SEARCH (To move the cursor to the desired
destination name)
1. When [F1] is pressed, "Please Input DEST
NAME =" will be displayed.
2. Input the destination name to be retrieved.
3. When [Enter] is pressed, the cursor will move
to the desired destination name.
[F2] : JUMP (To move the cursor to the desired destina-
tion number)
1. When [F2] is pressed, "Please Input DEST
NAME =" will be displayed.
2. Input the destination number to be retrieved.
3. When [Enter] is pressed, the cursor will move
to the desired number.
[F3] : Pg Up
When [F3] is pressed, the screen will display the 16
lines previous to the 16 lines displayed currently.
[F4] : Pg Dn
When [F4] is pressed, the screen will display the 16
lines next to the 16 lines displayed currently.
[F5] : PASTE (To copy the Description name)
1. Move the cursor to the destination number to be
copied.
2. Press [SPACE].
3. Move the cursor to the destination number to be
pasted, and press [F5].
n
Do not assign the same name to more than one destination.
. . . . . Source name setting procedure using
Description name
3. Set menu item [J] to the Description name mode.
Example:[J : NAME STYLE (DESCRIP. NAME)]
4. Select menu item [D].
5. Move the cursor to the desired source name.
6. When [Enter] is pressed, the Description name can be
typed. If the Description name is set already, delete it
by [BS].
7. Enter the Description name using the alphabet or
numerical keys. When [Enter] is pressed, the De-
scription name will be set.
ROUTING SWITCHER SYSTEM (E)
