Lockable 10-pin microphone connector for MXC gooseneck microphones.
③ Headphone Output
Two TRRS 3.5 mm ports on each side of the unit allow participants to listen to an interpretation channel or the floor audio
over headphones.
④ Volume Control
Two knobs on each side increase and decrease audio playback volume for headphones.
⑤ NFC Card Slot
Insert an NFC card to provide participant identification.
⑥ Touchscreen
View and select menu options on the display.
⑦ Microphone Buttons
Press to control the microphone. The buttons are customizable and function differently depending on the participant role
and meeting setup. See Using the Conference Units for more details.
⑧ Power Button
Press and hold to power the unit on or off. The button LEDs on the front of the unit light up red when it is powered on.
⑨ Battery Status Button
Press to check the remaining charge of the battery in the unit.
⑩ TRRS Port
Enables a remote caller to listen and be heard over the floor mix when a cell phone is connected.
⑪ Battery Slot
Insert an SB930 rechargeable battery to power on the unit.
⑫ USB Micro-B Connector
Connect a USB Micro-B cable to charge the battery in the conference unit.

Gooseneck Microphone (MXC416, MXC420, MXC406/MS)

The MXCW microphone delivers excellent audio performance with a frequency response specifically tailored for speech. There
are single and dualflex gooseneck options, providing flexible positioning. The gooseneck microphone also contains the follow­
ing features:
®
• Commshield Technology eliminates RF noise
• Locking 10-pin modular connector
• Built-in LED status indicator (LED ring)
• Compatible with the Microflex series cardioid, supercardioid, and omnidirectional cartridges
• Available in 15.75 in (40 cm) and 19.69 in (50 cm) lengths, as well as the MXC406/MS mini-shotgun microphone
