STAGe SeTTINGS
Press the STAGe button to
enter the Stage Menu
STAGE A SETTINGS

Mode

Ignition%
Mod Start
Copy Settings
Press the STAGe button
to go to the next stage
STAGE B SETTINGS
Mode
Ignition%
Mod Start

STAGe MeNu

STAGe: STAGE MENU
• This menu helps set the total number of active stages . In addition, it
offers the option to adjust the low fire setting and the lead percent firing at
which the lag stage starts .
• In most installations, all stage adjustments are the same . However, the
Multi-MOD Platinum offers a customized adjustment for each stage to
satisfy installations with different types of boilers .
• When all the stages are the same type of boiler, configure Stage "A"
settings then copy the settings to the rest of the stages . Everything but
the Mode will be copied .

MOVING AROuND THe STAGeS MeNuS

• Pressing the Stage button scrolls though the Stages' menus .
• Pressing the Next button displays the next adjustment .
MODe
Auto, Standby, Manual, Off, On
STAGe: STAGE MENU/Mode
• The Multi-MOD Platinum only controls the modulation of stages set to
Auto or (after a delay) those set to Standby . None of the other settings
are recommended for stages connected to active units .
Auto
• The Multi-MOD Platinum controls the stage's operation to maintain the
target .
• Only stages set to Auto can be lead stages .
Multi-MOD Platinum with Space and Scheduling Installation and Operation Manual
--- STAGE A MODE---
Auto
Manual
Standby
Auto
Off
1%
On
80%
------- STAGE A -------
Ignition Point
[
------- STAGE A -------
Modulation Start
Auto
1%
[
80%
COPY STAGE A
to all Stages
1%
]
80%
]

SETTINGS

Default: Auto
--- STAGE A MODE---
Auto
Manual
Standby
Off
On
- STAGE A MANUAL -
50%
[
STAGE A SETTINGS
Mode
Ignition%
Mod Start
Copy Settings
--- STAGE A MODE---
Auto
Manual
Standby
Off
On
AleRT
Any Stage not used ITS MODE
MUST BE SET TO OFF .
]
Auto
1%
80%
