M Enu - heat-timer Multi-MOD Platinum Installation And Operation Manual

SYSTeM STARTuP MeNu
------ SETTINGS ------
Shift
<System Settings>
<Schedules>
<Maintenance>
<System Startup>
SYS TEMP SENSOR TYPE
Standard
4-20ma
SENSOR 4mA VALUE
0 F
[
SENSOR 20mA VALUE
0 F
[
- OUTPUT TYPE A&B -
Not Installed
135ohm
0-10v
0-5v
2-10v
1-5v
4-20ma
- MODULATING MODE -
Normal
Parallel
------ HEAT/COOL ------
Heat
Cool
SENSOR FAULT MODE
Shutdown
All On
DAY LIGHT SAVINGS
Enable
Disable
Multi-MOD Platinum with Space and Scheduling Installation and Operation Manual
- SYSTEM STARTUP-
SELECT
To continue
- ARE YOU SURE? -
NO
YES
- EMS INPUT MODE -
Setback
EMS Control
EMS 4mA SETPOINT
140 F
] [
EMS 20mA SETPOINT
200 F
]
[
- OUTPUT TYPE C&D -
Not Installed
135ohm
0-10v
0-5v
2-10v
1-5v
4-20ma
- OPERATING MODE -
Normal
Process
------ Prove/DHW ------
Prove
DHW No Priority
DHW With Priority
DHW Using System
Reset Sensor
Type Only
------- SET YEAR -----
2012 YR
[
--- SENSOR TYPE ---
F
C
15psi
30psi
100psi
200psi
300psi
HWR
Reset F
Reset C
- STAGE INTERFACE -
Normal
MODBUS-Monitor Only
MODBUS-Full Control
STAGE A MODBUS ADD
] [
STAGE B MODBUS ADD
] [
---- DHW SET POINT --
180 F
[
- FAST COOL DOWN -
Minimum Water Temp
No Heat
------- SET MONTH -----
June
] July
1
]
0
]
]
25
