SYSTeM STARTuP
PReSS TO SeleCT: /<System Startup>
• The Startup menu settings are used to match the control logic to the
application . These settings must be set by a qualified installer .
• Several warnings are displayed when entering the Startup menu .
• On the first control power up, the System Startup menu screens will
appear after the control initialization is complete . If it doesn't, the
Multi-MOD Platinum has already been configured . To check the
configuration or to make changes, follow the System Startup menu steps .

SeNSOR TYPe

Temperature Options: Set Point: (°F, °C), HWR, Reset: (°F, °C),
Pressure Options: (15psi, 30psi, 100psi, 200psi, 300psi),
PReSS TO SeleCT: /<System Startup>/ Sensor Type
• The °F, °C, 15 PSI, 30 PSI, 100 PSI, 200 PSI, and 300 PSI are set point
options . That means, the control will modulate the stages to maintain a
fixed set point . See "Set Point" on page 32 .
• All Set point modes do not require an outdoor sensor . If an outdoor
sensor is connected in any of the Set Point modes it will be used only as
an outdoor cutoff .
• The Reset °F and Reset °C are designed to change the set point based
on the outdoor temperature and other reset parameters . See "Reset
Ratio" on page 33 .
• Reset modes require the use of an outdoor sensor .
• If the HWR Platinum is used to control the Multi-MOD Platinum, select the
HWR option . No system sensor is required in this case . See "Interfacing
to HWR" on page 20 .

SeNSOR TYPe TABle

SeT POINT
SeNSOR
TYPe
Range
˚F -40˚F to 250˚F
˚C -40˚C to 121˚C
15 PSI 0 .0 to 15 .0 PSI
30 PSI 0 .0 to 30 .0 PSI
100 PSI 0 to 100 PSI
200 PSI 0 to 200 PSI
300 PSI 0 to 300 PSI
♦ Available in Process Operating Mode only . See "Operating Mode" on page 28 .

SYSTeM TeMPeRATuRe SeNSOR TYPe

(Available when Sensor Type = °F , °C, Reset °F, Reset °C)
Standard, 4-20mA
PReSS TO SeleCT: /<System Startup>/ Sensor Type/ System Temp Sensor Type
• The Standard option uses Gold Series thermistor-type temperature
sensors . These sensor can measure temperatures up to 250°F / 121°C .
See "System Sensor" on page 17 .
26
Multi-MOD Platinum with Space and Scheduling Installation and Operation Manual
SeTBACk
Default Range
70˚F 1˚F to 80˚F
70˚C 1C˚ to 44C˚
10 .0 PSI 0 .0 to 7 .5 PSI 0 .0 to 3 .0 PSI
10 .0 PSI 0 .0 to 7 .5 PSI 0 .0 to 3 .0 PSI
30 PSI 0 to 75 PSI
60 PSI 0 to 150 PSI
80 PSI 0 to 200 PSI
Default: Set Point °F
lAST STAGe HOlD
Range Default
-10 to +10
0F° to 30F° 0F°
-10 to +10
0C° to 17C° 0C°
0 .0 PSI
0 .0 PSI
-10 to +10
0 to 10 PSI 0 PSI
0 .25 to 20 .0
0 to 20 PSI 0 PSI
0 to 30 PSI 0 PSI
Default: Standard
WARNING
The Startup settings must be
set by a qualified installer .
--- SENSOR TYPE ---
F
C
15psi
30psi
100psi
200psi
300psi
HWR
Reset F
Reset C
AleRT
The Multi-MOD Platinum
measures the System
Sensor input based on the
Sensor Type selected . See
"Sensor Type Table" below .
GAIN / THROTTle SYSTeM SeNSOR
(PROCeSS)
♦
Range Default
2
1 to 20
♦
1
1 to 11
♦
1 .0
♦
SYS TEMP SENSOR TYPE
Standard
4-20ma
TeRMINAlS
A1, A2
A5, A6
