Shifting from Night to Day
• The control uses the Day settings instead of the current Night settings .
The control stays in the Day mode until the control is shifted again or
until the next programmed Night Time . The display will show "DAY SHF"
to indicate this status .
Shifting from Day to Night
• The control uses the Night settings instead of the current Day settings .
The control stays in the Night mode until the control is shifted again or
until the next programmed Day Time . The display will show "NGT SHF"
to indicate this status .
Shifting to Extended Day
• The control uses the Day settings for an extended period . The extended
period is set by the Extend Day Time . The display will show "DAY EXT"
to indicate this status . When the control is manually shifted to Extended
Day, the Display will alternate between the "DAY EXT" and the remaining
extended time balance in minutes "DAY 89" to indicate this status . After
the extended period, the control reverts to the schedule .
• The Shift to Extended Day option is available to anyone with access to
the control . A Password restriction does not affect this option .
Shifting to Schedule
• This option exists the Shifting and resumes the scheduled operation .
• The Shift to Schedule option is available to anyone with access to the
control . Password restrictions does not affect this option .

DAY/NIGHT SCHeDule

Day Time #1, Night Time #1
Day Time #2, #3, #4, and Night Time #2, #3, #4
PReSS TO SeleCT: /<Schedules>/Day Night Schedule
• Use this setting to set up to 4 Day Time and 4 Night Time (Setback)
settings per each day of the week .
• If the Boost feature is being used, it uses the Day Time #1 setting . See
"Boost and Early Shutdown" on page 34 .
• The Night Time setting reduces the target temperature by the Setback
setting . Furthermore, if the ESD is used, the control uses the last Night
Time in calculating the ESD .
Schedule example
Schedule
MON
Day 6:00AM
#1
Night 10:00PM
♦♦
Day **:**
#2
Night **:**
Day **:**
#3
Night **:**
Day **:**
#4
Night **:**
♦ No boost will take effect .
♦♦ Early Shut Down ends . Night Schedule begins
Multi-MOD Platinum with Space and Scheduling Installation and Operation Manual
Tue WeD
6:00AM 6:00AM
10:00PM 10:00PM
♦♦ ♦♦
**:** **:**
**:** **:**
**:** **:**
**:** **:**
**:** **:**
**:** **:**
Default: 6:00 Am, 10:00 Pm
Default: **:**
Day of Week
THu FRI
6:00AM 7:00AM
10:00PM 11:00AM
♦♦
**:** 1:00PM
**:** 4:00PM
**:** 6:00PM
**:** 10:00PM
**:** **:**
**:** **:**
- EXTEND DAY TIME-
90 Min
[
------ SCHEDULES ------
MON # 1
Day Time
Night Time
SAT
**:** **:**
**:** **:**
8:00AM **:**
♦
4:00PM **:**
♦♦
**:** **:**
**:** **:**
♦♦
**:** **:**
**:** **:**
]
6:00Am
10:00Pm
SuN
