Fast Cool Down; Day Light Saving - heat-timer Multi-MOD Platinum Installation And Operation Manual

Reset Mode
• When All-On is selected, the Multi-MOD Platinum will turn all stages
On to a 100% when the System sensor reads
outdoor temperature is below Outdoor Cutoff . If the outdoor temperature
was above the Outdoor Cutoff; the Season was set to Summer; or the
Shutdown was active, the Multi-MOD Platinum will turn all the stages off .
• When Shutdown is selected, the Multi-MOD Platinum will turn all stages
Off when the System sensor reads
• When All-On is selected, the Multi-MOD Platinum will maintain the
Minimum Target temperature when the Outdoor reads
• When Shutdown is selected, the Multi-MOD Platinum will maintain the
Maximum Target temperature when the Outdoor reads

FAST COOl DOWN

(Available with Reset Modes Only)
Minimum Water Temperature, No Heat
PReSS TO SeleCT: /<System Startup>/ Sensor Type/.../Sensor Fault Mode/ Fast Cool Down
• The Fast Cool Down allows the building to cool down quicker when
starting the Night Schedule . It does that by lowering the target
temperature until the Space Average drops to the Night Target .
• For the Fast Cool Down to function, the Space Lock must be set to ON .
See "Space Lockout" on page 45 .
• When Minimum Water Temp is selected, the Multi-MOD Platinum reduces
the target temperature to the Minimum Target temperature when the
Schedule switches from Day (Normal) to Night (Saving) . This option
must be selected when the boiler manufacturer has a minimum boiler
temperature requirement .
• When Off is selected, the Multi-MOD Platinum reduces the target water
temperature to a minimum of 70°F when the Schedule switches from Day
(Normal) to Night (Saving) .
• When the building space temperature reaches the Night Target setting the
Multi-MOD Platinum will exit the Fast Cool Down operation and start its
night heating level .

DAY lIGHT SAVING

enable or Disable
PReSS TO SeleCT: /<System Startup>/ Sensor Type/.../ Fast Cool Down/Day Light Saving
• Enable this feature to account for the time changes in areas where Day
Light Saving is observed .
30
Multi-MOD Platinum with Space and Scheduling Installation and Operation Manual
or
Short Open
or .
Short Open
Short
Short
Default: Minimum Water Temperature
and the
or .
Open
or .
Open
- FAST COOL DOWN -
Minimum Water Temp
No Heat
DAY LIGHT SAVINGS
Default: enable
Enable
Disable
