MODulATION SPeeD

(Available in Process Mode Only)
Adjustable from 0.1 to 6.0 minutes
PReSS TO SeleCT: /<Maintenance>/Mod Speed
• Modulation Speed is designed to match the burner modulating speed to
the Multi-MOD's logic . This helps the Multi-MOD Platinum to respond
accurately to system changes . See "Operating Mode" on page 28 . .

leAD STAGe ROTATION

PReSS TO SeleCT: /<System Settings>/<More Settings>/<Stage Settings>/<Lead Settings>
• The Lead Stage is the first stage brought on when output is required .
• Rotating the lead stage evens the wear on each stage and prolongs the
life of the units .
• Only stages their Mode is set to Auto can be Lead . Therefore, not all
stages may be available when manually selecting a new lead stage .
• The current Lead Stage is shown in brackets on the display . <A>

leAD STAGe

Adjustable from A through D
PReSS TO SeleCT: /<System Settings>/.../<Stage Settings>/<Lead Settings>/Lead Stage
• Select a new lead stage from this menu . This menu option is primarily
used with Manual rotation option to select the lead stage .

leAD AuTO ROTATe

Manual, Time, last-On
Time is adjustable from 1 hour to 999 hours
PReSS TO SeleCT: /<System Settings>/.../<Stage Settings>/<Lead Settings>/Rotate Mode
• Automatically rotating the lead stage promotes even wear on all the
stages and prolongs their lives .
Manual
• In Manual, No rotation of lead stage . Select the lead stage manually from
the previous menu .
Time
• Timed rotation starts the lead stage followed by the lag stage . When
turning stages off, it turns off the lag stages before the lead stage .
Example: If stages "<A>", "B", and "C" are on while "<A>" is the lead,
then when turning off the stages it will turn off stage "C" followed by "B"
and then finally "<A>" .
• If 24 Hours (default setting) was selected, the first rotation will take effect
after 12 hours . The following rotations will take place every 24 hours
thereafter . However, if Time rotation was set to other than 24 hours, the
rotation timer will start from the moment the setting is changed .
last on
• Unlike Time rotation, Last-On turns off the last stage turned on last .
Example: If "<A>" is the lead, the starting sequence of the boilers will be
"A", "B", then "C" . When the turning off the stages, it will turn off "A", "B",
followed by "C" . Then, "<D>" will be the new lead stage .
38
Multi-MOD Platinum with Space and Scheduling Installation and Operation Manual
Default: 0.1 minutes
Default: A
Default: Time
Default: 24 hours
[
------ MOD SPEED -----
0.1min
[
AleRT
Adjust the Modulation Speed
to the motor with the slowest
modulation .
-- LEAD SETTINGS --
Lead Stage
Rotate Mode
140 F
<A> B C
50% --- --- STB
--- LEAD STAGE ---
A
B
C
D
LEAD AUTO ROTATE
Manual
Time
Last-On
AUTO ROTATE PERIOD
24 Hrs
]
D
Time
D
]
