Monday through Thursday: • Vari-Boost begins before 6 am and ends at 6 am
Friday:
Saturday:
Sunday:
If the control has space sensors configured, Boost can extend to an
additional hour if Day Target was not reached within the Boost period .

COPY SCHeDule

PReSS TO SeleCT: /<Schedules>/Copy Schedule
• This feature copies all Monday's schedule to the rest of the week .

SeT DATe AND TIMe

PReSS TO SeleCT: /<Schedules>/Set Date & Time
• To use the schedules, set the Date and Time .
• Internet capable controls get their date and time from the Internet
based on the Building Time Zone setting in the ICMS website .

VACATION SCHeDule SeTTING

Available in RINet (Internet Controls Only)
• The Vacation Schedule is used to reduce energy usage during
holidays . It does that by lowering the space target between two
date-time settings .
• The Vacation Space Target and settings can only be set and
activated using the ICMS website .
• The Vacation Schedule Enable must be On to set the Vacation
Schedule and Space Target .
44
Multi-MOD Platinum with Space and Scheduling Installation and Operation Manual
• Day temperature is maintained from 6 am until before 10 PM
• Early Shutdown starts before 10 PM and ends at 10 PM
• Night temperature is maintained from 10 PM until the Vari Boost the
following morning
• Vari Boost begins before 7 am and ends at 7 am
• Day temperature is maintained from 7 am to 11 am
• Night temperature is maintained from 11 am to 1 PM
• Day temperature is maintained from 1 PM to 4 PM
• Night temperature is maintained from 4 PM to 6 PM
• Day temperature is maintained from 6 PM until before 10 PM
• Early Shutdown starts before 10 PM and ends at 10 PM
• Night temperature is maintained from 10 PM until the following morning
• No Vari Boost because the #1 is not programmed
• Day temperature is maintained from 8 am until before 4 PM
• Early Shutdown starts before 4 PM and ends at 4 PM
• Night temperature is maintained from 4 PM into Sunday
• Night temperature is maintained all day Sunday, ending at the Vari Boost
Monday morning
AleRT
------ SCHEDULES ------
Copy Mon Schedules
To All Other Days
(Select to Execute)
---- DATE & TIME ---
Date Mon 10/20/12
Time
AleRT
The battery is the only backup for
the Date and Time during power
outage . The battery can hold the
date and time for up to 100 days .
10:04Am
