Assembly and installation

Signal status of inputs

PNP / Status
NPN
PNP active
DIP = OFF
in-active
NPN active
DIP = ON
in-active

Signal status of outputs

PNP / Status
NPN
PNP active
DIP = OFF
in-active
NPN active
DIP = ON
in-active

Schematics of all outputs

With PNP logic
U = Operating voltage
B
R = Internal overload protection
S
GND = Ground
28 von 54
ZONE_STOP ZONE_START
+ 24 V + 24 V
- -
GND GND
- -
ZONE_STATUS
+ 24 V
-
GND
-
CLEAR
+ 24 V
-
GND
-
ERROR
+ 24 V
-
GND
-
With NPN logic
Translation of the original operating manual
DIR_RET START /
ZONE_SENS_
IN
+ 24 V + 24 V
- -
GND GND
- -
EXT_ON
+ 24 V
-
GND
-
