Product information
3.6

Meaning of the LEDs

The LEDs indicate the operating condition of the ZoneControl and the RollerDrive and provide information about the
operating voltage.
LED green
Flashing
1)
On steady
Flashing
1)
On steady
On steady
On steady
Off
Off
Depending on the error, the LED flashes in different sequences (0.5 s on - 0.5 s off) within a period of 4 seconds.
1)
20 von 54
LED red
Flashing
1)
Off
Off
Flashes once
1)
Flashes twice
1)
Flashes three times
1)
Flashes four times
1)
On steady
Meaning
Initialisation of ZoneControl
ZoneControl ready for operation
RollerDrive receives start signal
RollerDrive faulty or not
connected
Fault in conveyor process (for
instance jammed package)
Shutdown due to excessive
temperature in chopper
resistance
System error (for instance PTP
cable disconnected)
Fuse triggered
Behaviour of RollerDrive
Depending on sensor assignment
Stop
Rotates
Stop
Stop
Stop
Stop
Stop
