Merlin Plus at a Glance

Take a few moments to familiarize yourself with the components of
your Merlin Plus:
1. Merlin Plus
2. Merlin Plus Power button
3. Viewing Mode button
4. Magnification dial (Size button)
5. Preset/Object Locator button
6. Focus Lock/Auto-Focus button
7. X-Y table
8. X-Y table locking lever
9. Recessed handles for carrying Merlin Plus
10. 3-foot RCA video cable
11. Power supply and power cord
12. VGA extension cable
13. Merlin Plus control box with coil cable
14. Foot Switch
15. Software cable and adapter
16. Merlin Plus Remote Software CD ROM
17. 3-foot S-Video cable
18. Light ON/OFF Switch
19. USB Adapter
Additional Options (not included)
20. 17" VGA Monitor
21. 20" TV Monitor with S-Video (not shown on page 7)
