Merlin Plus Specifications 38 - ENHANCED VISION Merlin Plus User Manual

Illumination:
Two user-replaceable 5-watt fluorescent bulbs (10,000-hr life)
Connections:
S-Video output for CCTV modes
RCA Composite video output for CCTV modes
RCA Composite video input for external camera modes
12VDC Power input
Computer VGA input (SUB-D15)
Split screen VGA output (SUB-D15)
Foot pedal jack input
Control box RJ-11 input
Power:
100-240V / 50-60Hz / 29W max
External power supply with removable power cord
Connector IEC-C13/14
Weight/Dimensions:
Base unit: 23lbs (10.5kg)
Height: 13.75" (35cm)
Length: 20.5" (52cm)
Width: 19" (48cm)
Environment:
Operating temperature:
Storage temperature:
Operating humidity:
Storage humidity:
Merlin Plus Specifications
+32F to 122F (0C to 50C)
-4F to 140F (-20C to 60C)
20% to 95%
20% to 80%
43
