ENHANCED VISION Merlin Plus User Manual page 16

About Merlin Plus Remote Software
Using the Default HOT KEYS
Default HOT KEYS have been programmed into the Remote Software
application.
Main Application Window
Windowing
Line Markers
Options
Width - Decrease
Width - Increase
Position - Decrease
Position - Increase
HOT KEYS allow for a quick operation of Merlin Plus without having to
maximize the software application window. For instance, from another
application, you may simply key in a preset HOT KEY combination and
Merlin Plus will react to it. There is no need to use the mouse. This allows
you to keep your hands on the keyboard at all times.
Note: The HOT KEYS serve the same function as the Control Box.
Programming New HOT KEYS
HOT KEYS may be reprogrammed to your liking or to avoid a conflict with
third party software. To view or change the HOT KEYS panel, you may
either:
• Right click on the EV icon (see figure 1 on page 15) and left click on HOT
KEYS on the drop down list.
• Left click on HOT KEYS in the Main Application Menu as shown in figure 2
on page 15. The HOT KEYS panel will then open as shown in figure 3.
To select a new HOT KEY, simply click on the function key icons that you
wish to use as the combination desired and select an alphanumeric key from
the drop down list. Your combination may include one or several keys.
CRTL and F5
CRTL and F6
CRTL and F7
CRTL and F8
CRTL and F9
CRTL and F10
CRTL and F11
CRTL and F12
16
figure 3
