ENHANCED VISION Merlin Plus User Manual page 41

Control Panel:
Intelligent focus lock:
Locator/Preset:
Zoom:
Mode:
External Control Box:
Window:
Options:
Lines:
Foot Pedal:
Voice Controls:
Auto-focuses upon zoom adjustment then freezes focus for tasks
requiring fixed focus
Quick locator finder that displays an onscreen target to help
orientation at high zoom levels
Allows 2-user defined zoom levels to be stored for convenience
16 preset zoom levels
Switches between 7 default video modes (up to 9 modes is possible
when 5 enhanced modes are stored)
Color
Black and White
Enhanced contrast Positive
Enhanced contrast Negative
Color select Yellow text on Blue background
Color select Green text on Black background
Color select Yellow text on Black background
Mode to enter interactive menu for settings adjustments:
Screen messages ON/OFF
Voice messages ON/OFF (Optional)
Voice recognition ON/OFF (Optional)
Voice training mode (Optional)
5 user defined color select modes
Adjusts the Video Magnifier/VGA split screen
Switches between split screen video modes
Adjusts horizontal or vertical line markers on CCTV video
Switches between split screen video modes
Change Video Magnifier video mode (Optional)
Increase magnification (Optional)
Decrease magnification (Optional)
Merlin Plus Specifications
