Honeywell Experion MX Operator's Manual page 79

access rights of the present Station operator. Figure 63 shows this popup as it would
appear for a Station user with Operator access rights.
Click button to open System setup & debug pop up as shown below.
Fig. 63.
Button/Field
Language
In Lost Time
Version
6510020335
QCS System Setup and Debug Dialog Box
Table 4: System Setup and Debug popup
Description
Click the drop-down to select the required language
Chooses that MIS data such as moisture and basis weight
spreads is not collected. This can be used in startup conditions or
during a big grade change when you know the product is off spec
and do not want the quality data collected
Displays the version number of the installed software.
EXPERION MX RAE STATION LAYOUT
79
