DEMO MANUAL DC1886B

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 0 CIN1, COUT2
2 1 COUT1
3 1 C2
4 1 D1
5 2 D2, D4
6 2 D3, D5
7 4 E1, E2, E3, E4
8 8 E5-E12
9 2 JP1, JP2
10 1 RMON
11 0 RSET
12 4 R1, R2, R3, R5
13 1 R4
14 3 R6, R7, R8
15 1 R9
16 1 R10
17 2
DC1886B-A Required Circuit Components
1
1 C1
0 CGS, CGATE
0 RGATE
1 U1
DC1886B-B Required Circuit Components
1
1 C1
0 CGS
1 CGATE
1 RGATE
1 U1
4
PART DESCRIPTION
CAP ., SANYO\16X25\H
CAP ., TANT, 22µF 25V, 20%, 7343
CAP ., X5R, 1µF 25V, 0603
DIODE, 400W TRANSIENT VOLTAGE
SUPPRESSOR, SMA-DIODE
LED, GREEN, LED-ROHM-SML-010FT
LED, RED, LED-ROHM-SML-010VT
TURRET, TEST PIN, 0.094"
TURRET, TEST PIN, 0.064"
JMP , HD1X3, 0.079CC
RES., CHIP , 20k, 1/8W, 5%, 0805
RES., CHIP , 0805
RES., CHIP , 3.3k, 1/16W, 5%, 0603
RES., CHIP , 150k, 1/16W, 5%, 0603
RES., CHIP , 20k, 1/16W, 5%, 0603
RES., CHIP , 140k, 1/16W, 5%, 0603
RES., CHIP , 226k, 1/16W, 5%, 0603
SHUNT, 0.079" CENTER
DC1886B-GENERAL BOM
CAP ., X5R, 1µF 25V, 0603
CAP ., 0603
RES., 0603
I.C., LTC4232IDHC, DFN16DHC
DC1886B-GENERAL BOM
CAP ., X5R, 0.1µF 25V, 0603
CAP ., X7R, 3300pF 100V, 5%, 0603
CAP ., X7R, 0.01µF 100V, 5%, 0603
RES., CHIP , 100k, 1/10W, 1% 0603
I.C., LTC4232IDHC-1, DFN16DHC
MANUFACTURER/PART NUMBER
OPT
AVX, TPSD226M025R0200
AVX, 06033D105KAT2A
DIODES INC., SMAJ22A-13-F
ROHM, SML-010FTT86L
ROHM, SML-010VTT86L
MILL-MAX, 2501-2-00-80-00-00-07-0
MILL-MAX, 2308-2-00-80-00-00-07-0
SULLIN, NRPN031PAEN-RC
YAGEO, RC0805JR-0720KL
OPT
YAGEO, RC0603JR-073K3L
YAGEO, RC0603JR-07150KL
YAGEO, RC0603JR-0720KL
YAGEO, RC0603JR-07140KL
YAGEO, RC0603JR-07226KL
SAMTEC, 2SN-BK-G
AVX, 06033D105KAT2A
OPT
OPT
LINEAR TECH., LTC4232IDHC
AVX, 06033D104KAT2A
AVX, 06031C332JAT2A
AVX, 06031C103JAT2A
NIC, NRC06F1003TRF
LINEAR TECH., LTC4232IDHC-1
dc1886bfa
