DEMO MANUAL DC2479A-B

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 CIN1
2 4 CIN2, CIN3, CIN4, CIN5
3 6 COUT1, COUT3, COUT5, COUT7,
COUT12, COUT14
4 1 C1
5 1 C4
6 1 C5
7 1 C7
8 3 C8, C9, C10
9 1 Q1
10 2 R1, R3
11 2 R2, R9
12 2 R4, R18
13 1 R11
14 1 R13
15 1 R16
16 1 R19
17 1 U1
Additional Demo Board Circuit Components
1 0 COUT2, COUT4, COUT6, COUT8,
COUT9, COUT10
2 0 COUT11, COUT13
3 0 C3, C11
4 0 R8, R10
5 2 R12, R14
6 0 R20
Hardware: For Demo Board Only
1 9 E1-E7, E17, E18
2 0 E8-E14
3 1 JP1
4 2 J1, J3
5 2 J2, J4
6 4 J2, J4 (×2)
7 2 J2, J4
8 2 J2, J4
9 2 J5, J6
10 1 XJP1
6
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
PART DESCRIPTION
CAP ., 150µF, 25V, Aluminum Electr.,
CAP ., X5R, 22µF, 25V, 10%, 1210
CAP ., X5R, 330µF, 4V, 20%,1210
CAP ., X5R, 220pF, 50V, 10%, 0603
CAP ., X5R, 2.2µF, 10V, 10%, 0603
CAP ., X7R, 4.7nF, 50V, 10%, 0603
CAP ., X5R, 0.1µF, 25V, 10%, 0603
CAP ., X7R, 1µF, 10V,10%, 0603
XSTR, SUD50N04-8M8P-4GE3 MOSFET
RES., 10, 1%, 1/10W, 0603
RES., 121k, 1%, 1/10W, 0603
RES., 10k, 1%, 1/10W, 0603
RES., 1k, 1%, 1/10W, 0603
RES., 2.55k, 1%, 1/10W, 0603
RES., 0.01Ω, 1W, 2512
RES., 90.9k, 1%, 1/10W, 0603
LTM4650EY-1#PBF , 16 × 16 × 5.01 BGA
CAP ., OPT, SANYO-D4D
CAP ., OPT, 1210
CAP ., OPT, 0603
RES., OPT, 0603
RES., 0Ω,1/10W, 0603
RES., OPT, 2512
TESTPOINT, TURRET, .094"
TESTPAD SMD
HEADER, 3 PIN 2mm SINGLE ROW
JACK BANANA
STUD, TESTPIN
NUT, BRASS 10-32
RING, LUG #10
WASHER, TIN PLATED BRASS
CONN,BNC,5 PINS
SHUNT 2mm
MANUFACTURER/PART NUMBER
SUN ELECT., 25CE150AX
MURATA, GRM32ER61E226KE15L
MURATA, GRM32ER60G337ME05L
AVX, 06035A221KAT2A
MURATA, GRM188R61A225KE34D
AVX, 06035C472KAT2A
AVX, 06033D104KAT2A
AVX, 0603ZC105KAT2A
VISHAY, SUD50N04-8M8P-4GE3
VISHAY, CRCW060310R0FKEA
VISHAY,CRCW0603121KFKEA
VISHAY, CRCW060310K0FKEA
VISHAY, CRCW06031K00FKEA
VISHAY, CRCW060320K55FKEA
VISHAY, WSL2512R0100FEA
VISHAY, CRCW060390K9FKEA
LINEAR TECH., LTM4650EY-1#PBF
OPT
OPT
OPT
OPT
VISHAY, CRCW06030000Z0EA
OPT
MILL-MAX, 2501-2-00-80-00-00-07-0
TESTPAD SMD
WURTH ELEKTRONIK, 620-003-111-21
KEYSTONE, 575-4
PEM KFH-032-10
ANY #10-32
KEYSTONE #10
ANY #10
CONNEX 112404
WURTH ELEKTRONIK, 608-002-134-21
