DEMO MANUAL DC1855A

parts List

ITEM QTY REFERENCE
Required Circuit Components
1 2 C1, C2
2 1 C3
3 1 C4
4 2 R5, R6
5 1 R8
6 1 R9
7 1 U1
Optional Demo Board Circuit Components
1 0 C5, C6
2 0 C7, C8
3 0 C9, C10
4 0 R1, R2, R3, R4
5 0 R7
6 0 R10
7 0 R11, R12
8 0 R13, R14
9 0 R15, R16
10 0 R17, R18, R19, R20
Hardware: For Demo Board Only
1 10 E1-E10
2 2 JP1, JP2
3 2 JP3, JP4
4 4 XJP1-XJP4
4
Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from
PART DESCRIPTION
CAP, X7R, 1µF, 25V, 20%, 0805
CAP, X5R, 22µF, 6.3V, 20%, 0805
CAP, X5R, 10µF, 6.3V, 20%, 0805
RES., CHIP., 237K, 1%, 1/16W, 0603
RES., CHIP., 54.9K, 1%, 1/16W, 0603
RES., CHIP., 113K, 1%, 1/16W, 0603
IC., LT3030EUFD, QFN28EUFD-4 × 5
CAP, X7R, 0.01µF, 25V, 10%, 0603
CAP, OPT, TANT, 4.7µF, 50V, 10%, 7343
CAP., OPT, 7343
RES., 1M, 5%, 1/16W, 0603
RES., CHIP., 54.9k, 1%, 1/16W, 0603
RES., CHIP., 113k, 1%, 1/16W, 0603
RES., CHIP., 249k, 1%, 1/16W, 0603
RES., CHIP., 402k, 1%, 1/16W, 0603
RES., CHIP., 732k, 1%, 1/16W, 0603
RES., OPT, 0603
TESTPOINT, TURRET, .095"
3 PIN, 0.079 SINGLE ROW HEADER
2 × 6, 0.079 DOUBLE ROW HEADER
SHUNT, .079" CENTER
MANUFACTURER/PART NUMBER
TDK C2012X7R1E105M
TAIYO YUDEN, JMK212ABJ226M
AVX, 08056D106MAT
VISHAY, CRCW0603237KFKEA
VISHAY, CRCW060354K9FKEA
VISHAY, CRCW0603113KFKEA
LINEAR, LT3030EUFD
AVX, 06033C103KAT2A
VISHAY, CRCW06031M00JNEA
VISHAY, CRCW060354K9FKEA
VISHAY, CRCW0603113KFKEA
VISHAY, CRCW0603249KFKEA
VISHAY, CRCW0603402KFKEA
VISHAY, CRCW0603732KFKEA
MILL-MAX, 2501-2-00-80-00-00-07-0
SAMTEC, TMM103-02-L-S
SAMTEC, TMM106-02-L-D
SAMTEC, 2SN-BK-G
dc1855af
