Parts List; Part Description - Linear Technology DC2147A Demo Manual

parts List

ITEM QTY REFERENCE
Required Circuit Components
1 1 CIN1
2 2 CIN2, CIN3
3 2 COUT1, COUT5
4 2 COUT2, COUT6
5 1 C2
6 2 C5, C7
7 2 C13, C14
8 2 C15, C16
9 1 Q1
10 4 R1, R3, R22, R26
11 1 R5
12 5 R9, R12, R15, R18, R25
13 2 R10, R13
14 1 R19
15 3 R24, R27, R36
16 1 R30
17 1 R37
18 1 U1
Additional Demo Board Circuit Components
1 0 COUT3, COUT7
2 0 COUT4, COUT8
3 0 C1
4 0 C3, C4, C6, C8 TO C12, C17, C18
5 0 R2, R4, R6, R8, R11, R14, R16,
R17, R20, R23, R28, R31, R33,
R39, R40, R41, R42
6 4 R7, R21, R29, R32
7 1 R34
8 0 R35
9 0 R38
Hardware: For Demo Board Only
1 16 E1, E3 TO E10, E12 TO E18
2 1 JP1
3 3 JP2, JP3, JP4
4 1 JP5
5 1 JP6
6 6 XJP1 TO XJP6
7 3 J1, J2, J3
8 6 J4 TO J9
9 4 (STAND-OFF)
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
DEMO MANUAL DC2147A

PART DESCRIPTION

CAP , 150µF, 25V, ALUMINUM ELECTR
CAP , X5R, 22µF, 25V, 20%, 1206
CAP , X5R, 100µF, 4V, 20%, 1206
CAP , 470µF, 2.5V, POSCAP , F8, 7343
CAP , X7R, 1µF, 25V,10%, 0805
CAP , X5R, 0.1µF, 25V, 10%, 0603
CAP , X7R, 0.01µF, 50V, 10%, 0603
CAP , X7R, 1µF, 10V,10%, 0603
XSTR,SUD50N04-8M8P-4GE3, MOSFET, TO252
RES, 10, 1%, 0603
RES, 121k, 1%, 0603
RES, 60.4k, 1%, 0603
RES, 6.04k, 1%, 0603
RES, 90.9k, 1%, 0603
RES, 10k, 1%, 0603
RES, 154k, 1%, 0603
RES, 0.05Ω, 1W, 2512
LTM4631EV#PBF , 16X16X4.41-LGA
OPT, 1206
OPT, 7343
OPT, 0805
OPT, 0603
OPT, 0603
RES, 0, 1%, 0603
RES, 0Ω, 0.5W, 2010
OPT, 2010
OPT, 2512
TESTPOINT, TURRET, 0.094"
HEADER, 2X4 0.079 DOUBLE ROW
HEADER, 1X3 0.079 SINGLE ROW
HEADER, 2X3 0.079 DOUBLE ROW
HEADER, 1X4 0.079 SINGLE ROW
SHUNT, 0.079" CENTER
CONN, BNC, 5 PINS
JACK BANANA
STAND-OFF , NYLON 0.50"
MANUFACTURER/PART NUMBER
SUN ELECT, 25CE150AX
TDK, C3216X5R1E226M160AB
TDK, C3216X5R0G107M160AB
SANYO, 2R5TPE470M9
AVX, 08053C105KAT2A
AVX, 06033D104KAT2A
AVX, 06035C103KAT2A
AVX, 0603ZC105KAT2A
VISHAY, SUD50N04-8M8P-4GE3
VISHAY, CRCW060310R0FKEA
VISHAY,CRCW0603121KFKEA
VISHAY, CRCW060360K4FKEA
VISHAY, CRCW06036K04FKEA
VISHAY, CRCW060390K9FKEA
VISHAY, CRCW060310K0FKEA
VISHAY,CRCW0603154KFKEA
VISHAY, WSL2512R0050FEA
LINEAR TECHNOLOGY, LTM4631EV#PBF
OPT
OPT
OPT
OPT
OPT
VISHAY, CRCW06030000Z0EA
VISHAY, CRCW20100000Z0EF
OPT
OPT
MILL-MAX, 2501-2-00-80-00-00-07-0
SULLINS, NRPN042PAEN-RC
SULLINS, NRPN031PAEN-RC
SULLINS, NRPN032PAEN-RC
SULLINS, NRPN041PAEN-RC
SAMTEC, 2SN-BK-G
CONNEX 112404
KEYSTONE, 575-4
KEYSTONE, 8833(SNAP ON)
dc2147af
7
