QUICK START PROCEDURE
Figure 2. Measuring Input or Output Ripple

PARTS LIST

ITEM QUANTITY
Required Circuit Components
1 1
2 1
3 1
4 1
5 1
6 1
7 2
8 1
9 1
Additional Demo Board Circuit Components
1 0
2 0
3 0
Hardware for Demo Board Only
1 9
2 1
3 1
Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from
V GND
IN
REFERENCE-DESCRIPTION
C1 Cap, X7R, 2.2μF , 50V, 10%,1206
CIN1 Cap, 22μF , 50V
C3 Cap, X5R, 22μF , 10V, 20%, 1206
C4 Cap, X7R, 0.1μF , 50V, 10%, 0603
R1 Res, 54.9k, 1%, 1/16W, 0603
R2 Res, 78.7k, 1%, 1/16W, 0603
R3, R5 Res, 100k, 1%, 1/16W, 0603
R4 Res, 10k, 5%, 1/16W, 0603
U1 IC, LTM8032EV, μModule
C10 (OPT) Cap, 1206
C11 (OPT) Cap, 22μF , 50V
L1 (OPT) Ind, High Current, Size 2525
E1 to E9 Turret
JP1 Header, 3 Pin 2mm
Shunt Shunt, 2mm
DEMO MANUAL DC1386B
100
90
80
70
60
50
40
30
20
10
0
0.01
OUTPUT CURRENT (A)
Figure 3. Effi ciency
DESCRIPTION
Murata GCM31CR71H225KA55L
Sanyo 50CE22BS
AVX 1206ZD226MAT2A
AVX 06035C104KAT2A
Vishay CRCW060354K9FKEA
Vishay CRCW060378K7FKEA
Vishay CRCW0603100KFKED
Vishay CRCW060310K0JNED
Linear Technology LTM8032EV#PBF
Mill-Max 2501-2-00-80-00-00-07-0
Samtec TMM-103-02-L-S
Samtec 2SN-BK-G
5.5V
IN
12V
IN
24V
IN
36V
IN
1 10
0.1
1386 F03
MANUFACTURER/PART NUMBER
dc1386bfa
3
