DEMO MANUAL DC1989A-B

parts List

ITEM QTY REFERENCE
Required Circuit Components
1 14 CIN1, CIN2, CIN4-CIN15
2 1 CIN3
3 10 COUT1, COUT6, COUT7, COUT9, COUT12, COUT17,
COUT18, COUT20, COUT23, COUT27
4 1 C3
5 8 COUT4, COUT5, COUT8, COUT15, COUT16,
COUT19, COUT26, COUT28
6 1 C7
7 1 C4
8 2 C5, C12
9 1 C21
10 1 C70
11 2 C65, C68
12 1 C67
13 1 C64
14 1 C66
15 1 C69
16 2 D1, D2
17 1 D3
18 1 J7
19 1 J8
20 1 J9
21 2 J10, J11
22 1 Q1
23 2 Q2, Q3
24 2 Q11, Q12
25 1 R20
26 25 R2, R4, R18, R25, R26, R120-R122, R30, R32, R47,
R48, R50, R56, R58, R60, R72, R74, R85, R86,
R89, R90, R92, R104, R119
27 4 R49, R51, R53, R54
28 16 R6, R7, R8, R9, R10, R11, R12, R15, R35, R36,
R39, R64, R78, R97, R98, R116
29 1 R27
30 1 R14
31 2 R16, R41
32 1 R112
33 1 R113
34 1 R19
35 1 R40
36 1 R42
37 1 R65
38 1 R66
8
PART DESCRIPTION
CAP., X5R, 10µF, 35V, 10%, 1210
CAP., 150µF, 35V, ALUMINUM ELECTR.,
CAP., X5R, 100µF, 6.3V, 20% 1210
CAP., X5R, 220pF, 16V, 10%, 0603
CAP., 330µF, 6.3V, POSCAP, D3L
CAP., X7R, 470pF, 16V, 10%, 0603
CAP., X7R, 3.3nF, 16V, 10%, 0603 (3300pF) AVX, 0603YC332KAT2A
CAP., X5R, 10nF, 16V, 10%, 0603 (0.01µF)
CAP., X5R, 100nF, 16V, 10%, 0603 (0.1µF)
CAP., X5R, 1µF, 25V, 10%, 0805
CAP., X5R, 1µF, 25V, 10%, 1206
CAP., X7R, 0.1µF, 25V, 10%, 1206
CAP., X5R, 4.7µF, 25V, 10%, 0603
CAP., X5R, 0.22µF, 25V, 10%, 0805
CAP., X7R, 150pF, 25V, 10%, 0603
LED GREEN S-GW TYPE SMD
LED RED S-TYPE GULL WING SMD
CONN HEADER 12POS 2MM STR DL PCB
PIN HEADER 20 DUAL ROW RA (M)
CONN SOCKET 20 DUAL ROW RA (F)
CONN, BNC, 5 PINS
MOSFET P-CH 20V 0.58A SOT-23
MOSFET N-CH 60V 115mA SOT-23
N-CHANNEL 30-V MOSFET, TO-252
RES., CHIP, 22.6k, 1%, 0603
RES., CHIP, 0Ω, 1%, 0603
RES., CHIP, 0Ω, 1%, 2010
RES., CHIP, 10k, 1%, 0603
RES., CHIP, 51k, 1%, 0603
RES., CHIP, 2k, 1%, 0603
RES., CHIP, 10Ω, 1%, 0603
RES., CHIP, 100Ω, 1%, 0603
RES., CHIP, 1.4k, 1%, 0603
RES., CHIP, 787Ω, 1%, 0603
RES., CHIP, 1.65k, 1%, 0603
RES., CHIP, 3.24k, 1%, 0603
RES., CHIP, 2.43k, 1%, 0603
RES., CHIP, 2.43k, 1%, 0603
MANUFACTURER/PART NUMBER
AVX, 1210DD106KAT2A
SUN ELECT., 35CE150AX
AVX, 12106D107KAT2A
AVX, 0603YD221KAT2A
SANYO, 6TPF330M9L
AVX, 0603YC471KAT2A
AVX, 0603YD103KAT2A
AVX, 0603YD104KAT2A
AVX, 08053D105KAT2A
AVX, 12063D105KAT2A
AVX, 12063C104KAT2A
MURATA, GRM188R61E475KE11
AVX, 08053D224KAT2A
AVX, 06033C151KAT2A
PANASONIC LN1371SGTRP
PANASONIC LN1271RTR
FCI 98414-G06-12ULF
Mill Max 802-40-020-20-0001
Mill Max 803-43-020-20-001
CONNEX, 112404
VISHAY TP0101K-T1-E3
FAIRCHILD 2N7002K
VISHAY, SUD50N03-09P-E3
VISHAY CRCW060322K6FKEA
VISHAY CRCW06030000Z0EA
VISHAY CRCW20100000Z0EA
VISHAY CRCW060310K0FKEA
VISHAY CRCW060351K0FKEA
VISHAY CRCW06032K0FKEA
VISHAY CRCW060310R0FKEA
VISHAY CRCW0603100RFKEA
VISHAY CRCW06031K40FKEA
VISHAY CRCW0603787RFKEA
VISHAY CRCW06031K65FKEA
VISHAY CRCW06033K24FKEA
VISHAY CRCW06032K43FKEA
VISHAY CRCW06032K43FKEA
