DEMO MANUAL DC2110A

parts List

ITEM QTY REFERENCE
Required Circuit Components
1 1 C1
2 1 C5
3 1 C6
4 1 C7
5 1 C8
6 1 C4
7 1 L1
8 1 L2
9 1 R1
10 2 R2, R4
11 1 R3
12 1 R5
13 1 U1
Additional Demo Board Circuit Components
1 1 C2
2 0 C11 (OPT)
3 0 D1 (OPT)
Hardware: For Demo Board Only
1 10 E1 TO E10
2 1 JP1
3 1 XJP1
4 0 R6 (OPT)
5 4 MH1 TO MH4
4
PART DESCRIPTION
CAP, 0.1µF, X7R, 10V, 10% 0402
CAP, 2.2µF, X5R, 10V, 10% 0402
CAP, 4.7pF, C0G, 50V, 0.25pF 0603
CAP, 47µF, X7R, 10V, 20% 1210
CAP, 0.1µF, X7R, 10V, 10% 0603
CAP, 1µF, X7R, 10V, 10% 0603
INDUCTOR, 22µH IHLP2525
INDUCTOR, 2.2µH
RES, 51.1k, 1/10W, 1% 0603
RES, 1M, 1/10W, 1% 0603
RES, 25.5k, 1/10W, 1% 0603
RES, CHIP, 191k, 1/10W, 1% 0603
IC, BUCK REG FE-20(16) CB
CAP, ALUM, 10µF, 100V
CAP, 0603
SCHOTTKY BARRIER REC, POWER-DI-123
TEST POINT, TURRET, 0.094" MTG.HOLE
4 PIN 0.079 SINGLE ROW HEADER
SHUNT, 0.079" CENTER
RES, 0603
STAND-OFF, NYLON 0.50"
MANUFACTURER/PART NUMBER
TDK, C1005X7R1A104K
TDK, C1005X5R1A225K050BC
MURATA, GRM1885C1H4R7CA01D
MURATA, GRM32ER71A476KE15L
AVX, 0603ZC104KAT2A
SAMSUNG, CL10B105KP8NNNC
VISHAY, IHLP2525CZER220M11
COILCRAFT, XFL4020-222MEB
VISHAY, CRCW060351K1FKEA
VISHAY, CRCW06031M00FKEA
VISHAY, CRCW060325K5FKEA
VISHAY, CRCW0603191KFKEA
LINEAR TECHNOLOGY, LT8631EFE#PBF
SUN ELECTRONIC, 100CE10BS
MILL-MAX, 2501-2-00-80-00-00-07-0
SULLIN, NRPN041PAEN-RC
SAMTEC, 2SN-BK-G
KEYSTONE, 8833 (SNAP ON)
dc2110af
