DSS-5000 Toyota Lexus
7. At the Edit Battery Info screen, tap on the corresponding
box to edit the parameter information.
NOTE: Battery Type, Units, and Rating must be
filled in before proceding.
Battery
Automotive
Application
Battery Post Top Post
Test
Top Post, Remote Post
Location
Battery
Flooded, AGM (Absorbed Glass Mat),
AGM Spiral, Gel, EFB
Type
CCA
Battery
Rating
Units
JIS
Battery
Enter the Battery Rating Units value.
Rating
Tap Next to begin the Battery Test.
8.

Battery Test Results

The test results are displayed on the Controller screen.

Additional Screens

The dots at the bottom or side of a menu or results screen
indicate additional screens are available. Swipe horizontally
or vertically across the Controller screen to view additional
results screens.
Screen 1

Screen 2

Screen 3

Swipe
Horizontally
www.midtronics.com
Cold Cranking Amps: 100 to
Battery current at 0 ºF 3000
(–17.8 ºC).
Japanese Industrial 26A17 to
Standard: Usually 245H52
printed on battery label.

Screen 1


Screen 2

Swipe
Vertically
Test Results - Battery Test
To print or send the test results to a configured printer tap
Send Results. To return to the Home Screen, tap Done or
System Test to continue with the System Test.
Cranking
Decision
Health
Good
Battery
Good
Good
Battery
Battery
Good
Recharge
Charge &
Retest
Good
Good
Recharge
Recharge
Charge &
Retest
Charge &
Retest
11
Midtronics Inc.
Chapter 2: In Vehicle Test
Reserve
Description
Capacity
Good Battery meets or exceeds
Battery required standards.
Unknown Battery meets or exceeds
Reserve required standards.
Good
Battery
Battery is good, but low
Good on charge. Fully charge
Battery
the battery for optimal
performance and life. Check
Unknown
for causes of low charge.
Reserve
Unknown Battery requires charge to
Reserve determine condition.
