Voltage
24.0 Volts
1
No Connections: Typical measure performed with the unit powered up only–no connections to the device.
2
Ethernet Connected Only: Typical power with Ethernet measured and the device attached to PC with Ethernet
cable only.
3
Maximum Current: Maximum current measured with Ethernet connected, SD Card, and USB Device actively
running read/write script, USB Debug and Host active running find/command.
4
Total Inrush Charge: The total inrush charge at power on expressed in Millicoulombs (mC).
Note:
Multi-Tech Systems, Inc. recommends that you incorporate a 10% buffer into the power source when
determining product load.
® TM
MultiConnect Conduit
No Connections Ethernet
1
(Amps) Connected only
(Amps)
0.081 0.086
Hardware Guide
Maximum
Current (Amps)
2
0.114
Total Inrush Total Inrush
3 4
Charge (mC) Charge Duration
(mS)
2.48 14.6
POWER DRAW
