BMS Connections

The network plug for AM 500, 800, 900, 1000 and 1200,
DV 1000 with AQC-P (grey control box) is named J5.
The network plug for AMC 150, AM 150 and 300 with AQC-L
(black control box) is named J18.
NB! Wiring must be connected according to the BMS
standard.
NB! Further information
documentation is available on Airmaster's website:
http://www.airmaster-as.com.

LON

®
Connection
J5/J18 Bus-A input and Bus-B input (polarity irrelevant)
D1 LON status LED, red
®
S1 Service Pin (test button)
Test
Status LED flashes.
Identification
Each individual network module has a Neuron
number is located on a label delivered with the module/
glued onto the control box in the unit. For example:
AQC LON
07 00 10 61 88 00
When programming, you can press the test button on the
network module to identify the units.
Cable Recommendation
A list of cables that comply with "Echelon® wire guidelines"
is available at http://www.echelon.com/
Wiring Guidelines' engineering bulletin").
on the D-BMS
ID. The ID
®
("Junction Box and
Appendix 1 - 33

KNX

®
Connection
grey KNX GND
®
red KNX +
®
D1 KNX status LED, green
®
SW2 KNX key, test button
®
Test
Status LED is green during programming.
Addressing
Each individual network module is supplied with the same
address: 15.15.254.
Press the test button on the network module to identify the
units and establish communication. The test button puts
the units into programming mode, enabling among other
things change of address to a unique address in the system.
Cable Recommendation
KNX®-registered, certified data cable (Twisted Pair (TP) or
Shielded Twisted Pair (STP). A list is available on the internet
athttps://www.knx.org.
Connection of Units
2 twisted-pair wires (1 pair) for KNX® GND and KNX® +
According to "KNX Association guidelines" [KNX® TP1
Installation, KNX® Association] it is not usually necessary
to connect the shield to the data cable if a typical standard
KNX® cable (e.g. KNX® TP1) is used in the installation.
