Standard Connections AM 500, 800 and 900 with AQC-P (Grey Control Box)

L
N
PE
S1
J6-A
J6-B
A2 (*1)
YE/
X1
OR
BU
GN
2
2 2
3
3 3
L N PE
3
1
EM
(*1)
4
2
YE/
X1
OR BU
GN
3 3 3
L
N PE
J 4
J 5
J1 Plug, option connection
J1-1 24 V (DC) output, one sensor
J1-2 GND (24 V)
J1-3 Alarm terminal clamp 1 (NO)
J1-4 Alarm terminal clamp 2
J1-5 Analogue BMS Start/External Emergency Stop,
digital input (DI#3)
J1-6 External start, digital input (DI#2)
J1-7 PIR signal, digital input (DI#1)
J1-8 12 V (DC) output
J1-9 12 V (DC) output
J1-10 GND PIR
J1-11 GND (CO signal, analogue BMS flow signal,
2
analogue BMS temperature signal)
J1-12 0-10 Volt CO signal input (AI#3)
2
J1-13 0-10 Volt analogue BMS temperature signal input
(AI#2)
J1-14 0-10 Volt analogue BMS flow signal input (linear)
(AI#1)
J3 Plug, control panel
J3-12V 12 V (DC) output
J3-GND GND (12 V)
J3-A + RS485 (A)
J3-B - RS485 (B)
J4/J15 Mini-B USB plug (PC connection)
J3-12V
J3-GND
J3-A
BU BU
J3-B
BU/BK
BU/BK
J1-9
J1-10
J1-9
J1-7
J 15
J1-1
J1-2
J1-11
A1
J1-12
J1-8
J1-6
J1-8
J1-5
J1-14
J1-11
J1-13
J1-11
J1-3
NO
S2
J1-4
COM
Appendix 1 - 26
OR
OR/BK
BU
BU/BK
1
2
7
8
< 24V/100mA/2VA
J5 BMS plug (LON®, KNX®, MODBUS®, BACnet
Ethernet
J6 Plug, RS485
J6-A + RS485 (A)
J6-B - RS485 (B)
(*1) Option
A1 Air handling unit
A2 Cooling module (*1; AM 500 and 800)
B1 Movement sensor (PIR) (*1)
B2 External CO sensor (*1)
2
EM Energy meter (*1)
P1 Control panel (*1)
S1 Supply separator (not supplied by Airmaster)
S2 Alarm contact
X1 Terminal clamps, power supply
External Emergency Stop, Boost - see section "Connection
of electrical equipment".
NB! All digital and analogue inputs can be programmed
using a PC with the "Airlinq Service Tool".
BK: Black
BU: Blue
12V GN: Green
GND OR: Orange
P1 (*1)
YE: Yellow
A
B
+ 12V
GND
B1 (*1)
Alarm
Alarm
24V
GND
B2 (*1)
GND
0-10V
External start
A-BMS start
0-10V
A-BMS flow
GND
0-10V
A-BMS temp.
GND
Alarm
COM
) ,
TM
