Connecting the AM 1000 Sections

J20
J21
J22
J23
J24
J25
J26
GND
CR (*1)
SKM230-T-B12
Output 1
Output 2
J20 Plug 1 left section
J21 Plug right section
J22 Plug 1 front section
(internal motion sensor) (IPIR) (*1)
J23 Plug 2 front section (AI) (*1)
J24 Plug 3 front section to plug 2 left section (ANC)
J25 Plug 3 left section (WCH) (*1)
J26 Plug 4 front section (IT)
CR Capacitive Return (*1)
CR-ED Exhaust Air Damper Capacitive Return (*1)
CR-SD Supply Air Damper Capacitive Return (*1)
SKM Capacity Unit Capacitive Return (*1)
GND Ground
(*1) Option
"J20"
"J21"
"J22" (*1)
"J23" (*1)
"J24"
"J25" (*1)
"J26"
"GND"
"CR-ED" (*1)
"CR-SD" (*1)
Appendix 1 - 28

Connecting the AM 1200 Sections

(*2) "IT"
J 7
(*2) "RT"
J 8
(*2) "ETV"
J 9
X1-L1 BN
4
(*2) "X2"
X1-N BU
4 3x0,75
X1-PE YE/GN
4
J15 BK
10
(*2) "X2"
J15
BU
11
2x0,25
J15
BN
26
(*2) "CO2" (*1)
J15 BK
27
J15 RD
28
K2
BN
T1
(*2) "CH"
X1-N BU
7
3x1,5*1
X1-PE
YE/GN
7
J16
BK
(*2) "X3" (*1)
5
X1-N BU
2x0,75
12
J16
BN
(*2) "MD"
2
X1-N
BU
11
BK: Black BU: Blue
BN: Brown GN: Green
X1 Terminal clamps, power supply (L1 – Phase 1,
N – Neutral, PE – Earth)
X2 Terminal clamps, condensate pump (CP) and
condensate float (FT)
J7 Plug, inlet temperature sensor (IT)
J8 Plug, room temperature sensor (RT)
J9 Plug, exhaust temperature sensor (ETV)
J15-10 Input 1 Condensate float (FT)
J15-11 Input 2 Condensate float (FT)
J15-26 Signal input, Internal CO
J15-27 Output GND Internal CO
J15-28 Output 24 V Internal CO
J16-2 Power supply (230 V) Main damper (MD)
(Connection only for models with roof ducts)
J16-5 Power supply (230 V) Water comfort heater
(WCH)
K2 Relay for electrical comfort heater (CH)
(*1) Option
(*2) Wire label
IT Sensor
RT Sensor
ETV Sensor
CP (*1)
FT
ICO (*1)
CH (*1)
M
WCH (*1)
MD
M
Spring-return
RD: Red
YE: Yellow
sensor (ICO) (AI#4)
2
sensor (ICO)
2
sensor (ICO)
2
