INSTALLATION
AM 150
300
500
800
.
.
.
1
2
2
.
.
3
3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AM 150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for airmaster AM 150

Summary of Contents for airmaster AM 150

  • Page 1 INSTALLATION AM 150...
  • Page 2 The unit should not be installed in rooms with This manual relates to the Airmaster unit it abrasive particles or flammable or corrosive gas accompanies plus all equipment, and must be in the air, in wet rooms or explosion-protected given to and saved by the unit’s owner.

  • Page 3: Table Of Contents

    3.5.1. Installation with Ceiling Frame .................................12 3.6. Installation of the Air Handling Unit AM 150, AM 150 with CC 150 (Cooling Module) and AM 300 ....13 3.6.1. Assembling the AM 150 and CC 150 before installation ....................13 3.6.2. Installation of the Air Handling Unit.............................. 13 3.6.3.
  • Page 4 Appendix 1 Dimensional Drawings ..............................17 AM 150, AM 150 - CC (with Cooling Module) and AM 300 ..........................17 AM 500 and 800 H ..........................................18 AM 500 and 800 V ..........................................19 AM 500 and 800 DIDE ..........................................20 AM 500 and 800 H - CF (Ceiling Frame) ..................................21 AM 500 and 800 V - CF (Ceiling Frame) ..................................22...

  • Page 5: General Information

    General Information 5. Ceiling fittings (optional) Scope of Delivery: The Airmaster air handling unit is packed on a pallet in one or more cardboard boxes. All individual parts can be found in the box(es), depending on the customer’s order. Please check the delivery before installation. The most important parts are shown below.

  • Page 6: Technical Specifications

    The diagram below shows the most important dimensions The installation engineer is responsible for ensuring that relating to the positioning of the unit. the Airmaster air handling unit is properly secured in a horizontal position. The installation engineer is responsible for ensuring that any existing functions in the wall/ceiling (e.g.

  • Page 7: Ceiling Brackets

    3.2. Ceiling Brackets   The purpose of the ceiling brackets is to hold a wall-mounted unit in place when the attachment to the wall frame alone does not provide sufficient support. This is the case, for example, when the unit is equipped with a cooling module, when the wall is not sufficiently sound or when the unit is to be fitted in a free-suspended position.

  • Page 8: Installation Of Wall Frames And The Drilling Of Duct Holes

    A rubber diaphragm for restoration of the function of the vapour barrier is optional available and can be delivered by Airmaster. Duct holes in the wall must have an outward downward gradient of 1-2% to prevent heavy rain from entering the unit.
  • Page 9 3. Mark the holes for the ducts according to “Appendix 1 Dimensional Drawings”. 4. Drill all marked holes. AM 150 and AM 300: See below. 5. Fit the wall frame. Only AM 150 and AM 300: 4. Drill the holes for the ducts and the frame (1, 2 or 1+2) in accordance with “Dimensional Drawings”.

  • Page 10: Installation Of The Cooling Module Cc 500 Or 800

    3.4. Installation of the Cooling Module CC 500 or 800 The cooling module has to be adjust into a horizontal position. 1. Drill, if relevant, any holes for the ceiling brackets according to the dimension drawings in “Appendix 2 Additional Dimensions” and attach the ceiling brackets 2.

  • Page 11: Installation Of The Air Handling Unit Am 500 And 800 To The Wall Frame Or Cooling Module

    This underlay may for example be strong, clean cardboard or equivalent. 3. Push the Airmaster air handling unit against the cooling module/wall frame and screw securely to the frame using the bolts provided.

  • Page 12: Installation With Ceiling Frame

    3.5.1. Installation with Ceiling Frame The unit has to be adjust into a horizontal position. 1. Drill the holes for the ducts and the frame in accord- ance with “Appendix 1 Dimensional Drawings” and “Appendix 2 Additional Dimensions”. (See also section “Wall Frame and Duct Holes”) The attachment point for the air handling unit on the ceiling frame for AM 500 and 800 is adjustable.

  • Page 13: Installation Of The Air Handling Unit Am 150, Am 150 With Cc 150 (Cooling Module) And Am 300

    5. Repeat on the other side. 6. Adjust the air handling unit into a horizontal position with the adjusting screws. For AM 150 with CC 150, it may be necessary to adjust between the units. Max pressure per adjusting screw:...

  • Page 14: Installation With Ceiling Frame

    At the AM 150 the supply air filter must be removed. 3. The long hinges mounted on the cabinet are mounted using the two screws that are provided on the service cover.

  • Page 15: Ducts And Grilles

    3.7. Ducts and Grilles 3.8. Roof Cap Fit roof caps on the roof to finish off the installation of exhaust and supply through a roof. Installation will depend The materials needed and method of fitting the ducting on the roof construction (3). The illustration shows which depend on the unit, the options chosen and the customer’s roof caps are for exhaust (1) and intake (2).

  • Page 16: Jointing Against The Ceiling

    3.10. Jointing against the ceiling 3.12. Installation Check Airmaster recommends jointing the gap between the unit’s yes no top plate and the ceiling if the unit is mounted in a fully Serial numbers noted visible manner. The jointing on the sides and in the front...

  • Page 17: Appendix 1 Dimensional Drawings

    Appendix 1 Dimensional Drawings AM 150, AM 150 - CC (with Cooling Module) and AM 300 See the attached dimensional drawing. Appendix 1 - 17...

  • Page 18: Am 500 And 800 H

    AM 500 and 800 H Shown here: AM 500 HB with Extract on the right side and one panel row. 1 = Exhaust 2 = Supply 3 = Inlet 4 = Extract 5 = Wall frame 6 = Condensate drain 7 = Electrical Connections 8 = Delivery + Return 1600...

  • Page 19: Am 500 And 800 V

    AM 500 and 800 V Shown here: AM 500 VC with Extract on the right side and two panel rows. 1 = Exhaust 2 = Supply 3 = Inlet 4 = Extract 5 = Wall frame 6 = Condensate drain 7 = Electrical Connections 8 = Delivery + Return Holes to be drilled for ducts:...

  • Page 20: Am 500 And 800 Dide

    AM 500 and 800 DIDE Shown here: AM 500 HDIDE with Extract on the right side and three panel rows. 1 = Exhaust 2 = Supply 3 = Inlet 4 = Extract 5 = Wall frame 6 = Condensate drain 7 = Electrical Connections Ø250 8 = Delivery + Return...

  • Page 21: Am 500 And 800 H - Cf (Ceiling Frame)

    AM 500 and 800 H - CF (Ceiling Frame) Shown here: AM 500 HT - CF with Extract on the right side and three panel rows. 1 = Exhaust 2 = Supply 3 = Inlet 4 = Extract 5 = Ceiling Frame 6 = Condensate drain 7 = Electrical Connections 8 = Delivery + Return...

  • Page 22: Am 500 And 800 V - Cf (Ceiling Frame)

    AM 500 and 800 V - CF (Ceiling Frame) Shown here: AM 500 VT - CF with Extract on the right side and three panel rows. 1 = Exhaust 2 = Supply 3 = Inlet 4 = Extract 5 = Ceiling Frame 6 = Condensate drain 7 = Electrical Connections 8 = Delivery + Return...

  • Page 23: Am 500 And 800 H - Cc (With Cooling Module)

    AM 500 and 800 H - CC (with Cooling Module) Shown here: AM 500 HB-CC with Extract on the right side and one panel row. . 1 = Exhaust 2 = Supply 3 = Inlet 4 = Extract 5 = Wall frame 6 = Condensate drain 7 = Electrical Connections 8 = Delivery + Return...

  • Page 24: Am 500 And 800 Hdide - Cc (With Cooling Module)

    AM 500 and 800 HDIDE - CC (with Cooling Module) Shown here: AM 500 HDIDE-CC with Extract on the right side and three panel rows.. 1 = Exhaust 2 = Supply 3 = Inlet 4 = Extract 5 = Wall frame 6 = Condensate drain Ø250 7 = Electrical Connections...

  • Page 25: Isometric View

    Isometric View AM 500H AM 500H DIDE AM 800H AM 800H DIDE 1 = Exhaust 3 = Inlet 5 = Wall Frame 7 = Electr. Connection 2 = Supply 4 = Extract 6 = Condensate Drain 8 = Delivery + Return Appendix 1 - 25...
  • Page 26 AM 500V AM 500V DIDE AM 800V AM 800V DIDE 1 = Exhaust 3 = Inlet 5 = Wall Frame 7 = Electr. Connection 2 = Supply 4 = Extract 6 = Condensate Drain 8 = Delivery + Return Appendix 1 - 26...
  • Page 27 AM 500 H - CF (Ceiling Frame) AM 500V - CF (Ceiling Frame) AM 800H - CF (Ceiling Frame) AM 800V - CF (Ceiling Frame) 1 = Exhaust 3 = Inlet 5 = Ceiling Frame 7 = Electr. Connection 2 = Supply 4 = Extract 6 = Condensate Drain 8 = Delivery + Return...
  • Page 28 AM 500 H - CC (with Cooling Module) 6 (AM) 6 (CC) 6 (CC) AM 800H - CC (with Cooling Module) 6 (CC) 6 (AM) 6 (CC) 1 = Exhaust 3 = Inlet 5 = Wall Frame 7 = Electr. Connection 2 = Supply 4 = Extract 6 = Condensate Drain...

  • Page 29: Model Versions Am 500 And 800

    Model Versions AM 500 and 800 Version T: Inlet top. Version C: Inlet middle. Version B: Inlet bottom. Version DI: Ducted inlet. Version DE: Ducted Extract. Version RE: Supply and Exhaust with square spigots. 1040 Appendix 1 - 29...

  • Page 30: Appendix 2 Additional Dimensions

    Connections AM 500 - CF (Ceiling Frame) Appendix 2 Additional Dimensions Connections AM 500 44** 44** 106*** 82*** 678** 49** 49** 1504*** 1479*** = Condensate Drain = Electrical Connection = Delivery + Return AM 500: Delivery is towards the front. From top edge of wall / ceiling frame.

  • Page 31: Connections Am 500 - Cc

    Connections AM 500 - CC Connections AM 800 48** 82*** 1491*** 1814*** 55** 792** 1084** 1830*** 54** 94*** Connections AM 800 - CF (Ceiling Frame) 48** 1479*** 1838*** 1854*** 6.1 = Condensate Drain AM 6.2 = Condensate Drain CC = Electrical Connection = Delivery + Return 118*** AM 500: Delivery is...

  • Page 32: Connections Am 800 Dide

    Connections AM 800 DIDE Connections AM 800 - CC 55** 48** 70*** 1814*** 1814*** 1566** 1198** 797** 699** Ø250 54** 1830*** 1830*** 1065*** 94*** 94*** 6.1 = Condensate Drain AM 6.2 = Condensate Drain CC = Electrical Connection = Delivery + Return AM 800: Return is towards the front.

  • Page 33: Connections Am 800 Dide - Cc

    Connections AM 800 DIDE - CC Ceiling Bracket, Angle 54** Ø6 70** 1814*** 1972** 1203** 699** Ø250 54** 1830*** Ø8,3 1065*** Ø8,3 Ceiling Bracket, Adjustable 94*** 6.1 = Condensate Drain AM 6.2 = Condensate Drain CC = Electrical Connection = Delivery + Return AM 800: Return is towards the front.

  • Page 34: Postioning Of The Ceilling Brackets

    Postioning of the Ceilling Brackets AM 500 and 800 Distance (A) wall Optical distance frame to ceiling unit to ceiling min. max. min. max. d1** d2** e*** f*** g*** h*** 11,5 26,5 15,5 47,5 1525,5 1557,5 18,5 15,5 47,5 1835,5 1867,5 800 (DE) 18,5 15,5...

  • Page 35: Postioning Of The Ceilling Frame

    Postioning of the Ceilling Frame AM 500 and 800 g*** h*** i*** j*** k*** 1501 1612 1811 1922 From wall. From left edge of ceiling frame. Appendix 2 - 35...
  • Page 36 Airmaster A/S Tel.: +45 98 62 48 22 Industrivej 59 info@airmaster-as.com DK-9600 Aars www.airmaster-as.com/en/...
