5.5.

System Programming

NB! All programming is carried out using the Airlinq
Service Tool program that is running on the unit to be
programmed, i.e. on the unit's control box or cooling
module, or on the control panel.
Units in an Airlinq BMS system must be grouped in the
building, according to the customer's requirements. This
physical grouping is programmed in the master (system
0, unit 0, ID0) using a PC running the Airlinq Service Tool
program. A group could, for example, be room 102 with unit
2 (unit 2, ID2) and unit 3 (unit 3, ID3). In each group, one unit
is programmed to be the unit that determines the group's
operations (Group Master).
All units must be programmed with the group identity (group
ID) to which the unit in question must belong as well as their
own identity (Communication ID). A cooling module must be
paired with the unit on which the cooling module is installed.
The cooling module's identity must be programmed. Further
details are available in the programming instructions below
and in the pairing table to the right.
An Airlinq Viva control panel, which is used as a group control
panel, must be programmed with its allocation to a specific
group (Group ID) and its own identity (Communication ID).
Further details are available in the programming instructions
below and in the pairing table to the right.
NB! The maximum number of group control panels per
system is 19. A system must always be supplied with an
Airlinq Orbit control panel as the system control panel.
The Airlinq Orbit control panel is programmed with the
following identity ex works: ID179 (Communication ID).
This setting should not be changed.
When all programming has been completed, the entire
system can be put into operation. Further details are avail-
able under "Commissioning and final inspection".
Pairing of units with cooling modules:
Unit identity
(Communication ID)
ID0
ID1
ID2
...
ID18
ID19
Pairing of Airlinq Viva with groups:
Group identity
(Group ID)
G0
G1
G2
...
G17
G18
16
Cooling module identity
(Communication ID)
ID100
ID101
ID102
...
ID118
ID119
Viva identity
(Communication ID)
ID160
ID161
ID162
...
ID177
ID178
