Eagle Access Control Systems X9S Installation & Owner's Manual page 6

Swing Gate Recommendations
Gates should have smooth bottom edges, with vertical bottom edged protrusions not exceeding 0.50 inches.
Gate Closed
1 If distance is greater than 4 inches,
entrapment protection for this area
is recommended.
2 If distance is less than 16 inches,
entrapment protection in this area
is recommended.
The operator is intended for installation ONLY on gates used for vehicles.
access opening. The pedestrian access opening should be designed to promote pedestrian usage. Locate the gate such that
persons will not come in contact with the vehicular gate during the entire path of travel of the vehicular gate.
4
1
2
Gates Closed
Gate Closed
With the hinge mounted on
the corner of the pilaster, the
entrapment area 1 is
eliminated and protection is
NOT needed for this area.
Separate
Pedestrian
Access
Opening
Pedestrians should be supplied with a separate
X9 Swing Rev - H
