Eagle Access Control Systems X9S Installation & Owner's Manual page 11

Option
Weld Bracket at an Angle
NOTE: Weld COMPLETELY around bracket.
Option
Cut Bracket to Fit
4"
2"
Rear Bracket
Not Level
Not Level
X9 Slide Rev - H
MOUNT ARM
Arm MUST be Installed LEVEL!
2" Offset Between Brackets
COMMON MISTAKES
TO BE AWARE OF:
4" Minimum Above Ground
X9L-Long Arm
Min Stroke
18 3/4"
38 1/2"
X9S-Short Arm
Min
18 3/4"
32 1/2"
NOTE: Release the stroke pin before installation,
see "Release Stroke Pin" on previous page.
Not Level
Upside Down
Max Stroke
19 5/8"
Max
Stroke Pin
13 3/4"
See pages 11 and 12 for
dimensional layouts.
Front Bracket
3 3/4"
9
